Schurter 10A Time Delay Ceramic Cartridge Fuse 6.3 x 32 mm 500V ac SHT 6.3x32 8020.5021.G

Schurter 8020.5021.G ceramic Cartridge Fuse is a precision-engineered electrical protection device rated for 10A current and 500V AC voltage. It features a robust ceramic cylindrical body that offers excellent insulation and thermal resistance, making it suitable for demanding industrial and commercial electrical circuit protection.

The fuse is designed with time delay characteristics (T-class) allowing it to withstand transient current surges without blowing, thus providing reliable protection for circuits containing motors, transformers, and inductive loads. The ambient operating temperature range spans from -40°C to 85°C, ensuring stable performance under varying environmental conditions.

Construction includes nickel-plated copper alloy end caps and tin-plated copper axial leads, providing low resistance and durability. It has a high breaking capacity of 1500A at AC and 1000A at DC, capable of interrupting fault currents in electrical installations safely.

This fuse is part of the SHT 6.3x32 series and is commonly used in three-phase electrical systems, DC systems, photovoltaic installations, and power electronic devices such as frequency converters. Its compact form factor (6.3 mm diameter and 32 mm length) allows easy integration into standard fuse holders and clips.

Made with a durable ceramic cylindrical body for enhanced reliability. Rated for an ambient temperature range from -40°C to 85°C. Nickel-plated copper alloy end caps and tin-plated copper axial leads ensure excellent conductivity.

Breaking capacity of 1500A AC and 1000A DC suitable for industrial electrical protection. SHT 6.3x32 series fuse suitable for 3-phase systems and DC system applications. Designed for pulse-shaped continuous current and frequency converters.

Complies with RoHS, UKCA, UL, CE, and cURus standards and approvals. Compact size of 6.3 mm diameter and 32 mm overall length for easy installation in fuse holders.

Applications span across industrial electrical protection, power electronics, photovoltaic systems, and frequency conversion equipment in commercial and laboratory environments. This fuse helps ensure circuit safety and contributes to the longevity of connected equipment by preventing overcurrent damage.
