Cosel DC/DC Converter 5V DC, 6A, 36V DC Input, 30W PCB Mount STMGFS302405-N1

Cosel STMGFS302405-N1 is a high-quality DC/DC Converter providing a stable 5V DC output at 6A current and 30W maximum power, designed for surface PCB mounting. It supports a broad DC input voltage range from 9V up to 36V, with a ripple and noise specification of 200mV, making it suitable for sensitive electronic circuitry.

This converter series features built-in protections including overcurrent protection with automatic recovery, overvoltage protection specific to the STMG30 model, and a remote ON/OFF function for enhanced control. Output voltage can be adjusted within ±10% for fine tuning the power delivered to the load.

The compact form factor of 117mm length, 52mm width, and 27mm depth, along with an isolation voltage rating of 500V DC, ensures safe operation and easy integration into industrial, laboratory, manufacturing, and commercial electronic power supply systems. The device operates efficiently with approximately 90% efficiency, reducing heat generation and energy waste.

The STMGFS series converters are engineered in Japan and comply with international standards such as cUL, EN, UL, RoHS, CE, and CSA, underscoring their reliability and safety. With a wide operating temperature range extending from -70°C to 70°C, this converter is suitable for harsh environmental conditions encountered in industrial applications.

Typical uses include power supplies for industrial electronic instrumentation, control systems, communications equipment, and other embedded electronics requiring stable low-voltage DC supply from fluctuating DC inputs.

High efficiency and compact PCB mounting design. Wide input voltage with multiple protections built in. Single output with adjustable voltage range for precise applications. Wide operating temperature suitable for industrial environments.
