TDK-Lambda CC-E Series DC/DC Converter 12V dc, -12 V dc Output, 250 mA, 24V dc Input, 6 W, Through Hole Mount CC6-2412DF-E

The TDK-Lambda CC6-2412DF-E is a reliable CC-E Series DC/DC Converter providing dual output voltages of +12V and -12V DC at 250 mA output current with a maximum output power of 6 W. It accepts a DC input voltage range of 22.8 V to 24 V, making it suitable for a variety of power supply systems.

This converter features a compact, through hole DIP package measuring 22.86mm in length and 8.5mm in width and depth, weighing only 4.5 grams. Its metal casing ensures reduced radiated EMI for improved electromagnetic compatibility in sensitive electronic environments.

The CC-E Series is designed for robust industrial applications including test and measurement equipment, broadcast systems, process control instrumentation, and general industrial purposes. It maintains high conversion efficiency (~86%) and is rated to operate reliably within a temperature range of -40°C to 85°C.

The isolation voltage of 500V AC ensures electrical separation between input and output, enhancing safety and protecting sensitive circuit components. It also conforms to multiple international standards and approvals such as CE, cULus, UL CSA 60950-1, EN 60950-1, and NEMKO, assuring quality and compliance for professional use.

The device offers an output voltage adjustment range of ±15 V DC for flexibility in fine-tuning output to match specific load requirements. Its 7-pin DIP configuration facilitates straightforward PCB mounting and integration.

Compact through hole mount design suitable for PCB integration. High efficiency conversion with 86% typical efficiency. Wide operating temperature range from -40°C to 85°C. Provides dual output voltages with ±15 V dc adjustment range.

Electrical isolation voltage rated at 500V AC. Complies with CE, cULus, UL CSA 60950-1, EN 60950-1, and NEMKO safety standards. Lightweight with metal case for EMI reduction. Ideal for test, measurement, broadcast, and process control applications.

Package type is DIP with 7 pins for connection. Dimensions approximately 22.86mm length, 8.5mm width and depth.

For professional industrial applications requiring DC voltage conversion with reliable performance and compliance, the TDK-Lambda CC6-2412DF-E offers a trusted solution. Explore more products in the DC/DC Converter category on EnvMart for your electronic component needs.
