RS PRO Circular Connector, 3 Contacts, Cable Mount Plug, Male, Standard Size, Threaded Mating, 500V, 10A, IP68 124-6687
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 500V |
| Brand | RS PRO |
| Orientation | Straight |
| Current | 10A |
| Model | 124-6687 |
| IP Rating | IP68 |
| Mount Type | Cable |
| Housing Material | Polyamide 66, Polycarbonate |
| Contact Material | Brass |
| Series | RS PRO |
| Termination Type | Screw |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -40°C |
| Pole Format | 3 |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shell Size | 21 mm |
| Mating Type | Threaded |
| Connector Size | Standard |
| Plug/Socket | Plug |
Key Features
- Features high IP68 ingress protection rating for water and dust resistance.
- Constructed with robust polyamide 66 and polycarbonate housing materials.
- Gold-plated brass contacts ensure reliable conductivity and corrosion resistance.
- Screw termination allows easy assembly without special tooling.
- Operates in temperature range -40°C to +85°C, suited for harsh environments.
- Accepts cable outer diameters from 7 mm to 12 mm.
- Supports 500V voltage and 10A current rating for industrial power needs.
- Three pole configuration with male contact gender and standard size shell.
Product Description
The RS PRO 124-6687 circular connector is a cable mount plug featuring 3 contacts, designed for industrial use with threaded mating. Its robust construction with a polyamide 66 and polycarbonate housing ensures durability in demanding environments, while providing a secure IP68 rated watertight and dust-tight connection. This connector supports an operating voltage of 500V and current rating of 10A, suitable for power and signal applications.
With gold-plated brass contacts and screw termination, the connector offers reliable electrical performance and easy installation without specialized tools, making it highly suitable for field applications requiring regular maintenance. The temperature rating from -40°C to +85°C enables use in extreme conditions such as industrial robotics and automation systems.
The connector shell size is standard 21 mm, featuring a straight orientation and threaded mating type for secure mechanical coupling. Cable acceptance of 7 to 12 mm outer diameter adds versatility for cable selection. This model is manufactured in China and part of the RS PRO series.
Robust nylon and polycarbonate housing materials with V-0 fire rating provide mechanical and fire safety. Gold plated brass contacts assure superior conductivity and corrosion resistance. IP68 rating guarantees protection against dust ingress and immersion in water.
Screw termination enables quick and tool-free assembly and maintenance. Suitable for diverse industrial environments including process control, machine tooling, and industrial automation.
This RS PRO circular connector model 124-6687 is an excellent choice for industries demanding reliable, waterproof, and robust circular connectors. It facilitates cable to cable or cable to panel connections with threaded locking mechanisms for secure engagement. Explore more RS PRO connectors and accessories on EnvMart for your industrial connectivity needs.
Explore more products in our Industrial Circular Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a maximum voltage of 500V and a current rating of 10A, making it suitable for industrial power needs.
It has an IP68 ingress protection rating, ensuring it is resistant to dust and capable of withstanding immersion in water.
The housing is made from polyamide 66 and polycarbonate, while the contacts are gold-plated brass for reliable conductivity and corrosion resistance.
It operates within a temperature range of -40°C to +85°C, suitable for harsh environments.
The connector shell size is standard at 21 mm, designed for compatibility with various applications.
This model features 3 contacts, with a male contact gender configuration.
It utilizes screw termination, allowing for easy assembly without the need for special tools.
It accepts cable outer diameters ranging from 7 mm to 12 mm, providing versatility for different cable types.
This model features a threaded mating type, ensuring a secure mechanical coupling.
It is suitable for diverse industrial environments including process control, machine tooling, and industrial automation.
This model is manufactured in China, as indicated by its country of origin.
Gold plating on the contacts ensures superior conductivity and corrosion resistance, enhancing the reliability of electrical performance.
