Amphenol Industrial EV Connector SURLOK PLUS RADSOK Male 300A 1000V Crimp Termination SLPPC70BSB0 / C10-730190-1700
Specifications
| Country of Origin | China |
|---|---|
| Brand | Amphenol Industrial |
| Colour | Black |
| Orientation | Right Angle |
| Current | 300A |
| Height | 88.5mm |
| Model | SLPPC70BSB0 / C10-730190-1700 |
| Depth | 40.5mm |
| IP Rating | IP67 |
| Connector Type | RADSOK |
| Width | 30.3mm |
| Mount Type | Cable |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | SURLOK PLUS |
| Termination Type | Crimp |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Pin Diameter | 10.3mm |
| Number of Rows | 1 |
| Wire size | 70mm² |
| Operating Voltage | 1000V |
| For Use With | SurLok 1-Position Receptacle |
| Standards/Approvals | UL 94-V0 |
| Number of Contacts | 1 |
| Contact Gender | Female |
| Connector Gender | Male |
| Better World Claim | Renewable Energy Solution |
Key Features
- The connector features a spring locking mechanism ensuring a quick lock and press-to-release operation.
- It is designed with a 10.3mm pin diameter and right angle orientation for ease of installation.
- The housing is made of thermoplastic material providing UL 94-V0 flammability rating and a black color finish.
- Rated for an IP67 ingress protection, suitable for harsh environments and renewable energy applications.
- Supports operating temperature range from -40°C to 125°C for reliable performance.
- Contact material consists of copper alloy ensuring high conductivity with R4 Radsock technology for strong tensile strength.
- Designed for cable mount type and intended for use with SurLok 1-Position Receptacle connectors.
Product Description
Amphenol Industrial SLPPC70BSB0 / C10-730190-1700 is an advanced EV Connector from the SURLOK PLUS series specifically engineered for high current and voltage applications up to 300A and 1000V respectively. This male RADSOK type connector supports a 70mm² wire size and provides a reliable crimp termination ensuring a secure and maintenance-friendly connection.
The connector features a compact design with a pin diameter of 10.3mm and a right angle orientation, facilitating easy integration into electric vehicle, rail mass transit, battery management systems, and heavy equipment applications. Its durable thermoplastic housing meets the UL 94-V0 flammability standard and comes in a black color, offering strength and safety in demanding environments.
Built with the innovative R4 Radsock technology, the connector ensures a high tensile strength and a large conductive surface area for efficient current transfer. The spring locking mechanism offers a 360° rotation and a keyed design to prevent mismating, enhancing safety and operational reliability. Rated IP67, it is protected against dust ingress and temporary immersion in water, suitable for outdoor and rugged industrial environments.
The wide operating temperature range from -40°C to 125°C makes this connector ideal for harsh conditions and diverse industrial uses. Common applications include electric vehicles (EV/HEV), rail mass transit, process control, medical equipment, and renewable energy systems requiring robust power interconnectivity.
The connector rotates 360° and features a touch-proof design for enhanced user safety. Spring locking and keyed features prevent unintended disconnection and mismating. IP67 rating ensures dust-tight and water-resistant protection.
Thermoplastic housing material meets UL 94-V0 flame retardancy standard. Copper alloy contacts with R4 Radsock technology provide excellent conductivity and mechanical strength. Compact footprint with dimensions 88.5mm (H) x 30.3mm (W) x 40.5mm (D) facilitates installation in confined spaces.
This connector is a component of Amphenol's SURLOK PLUS range, delivering innovative, high-performance electrical connection solutions for demanding industrial environments. Discover more sustainable, high-quality electronic components at EnvMart's Electronics Components and EV Connector category.
