Amphenol Industrial EV Connector SLP Plug Female 35mm² Wire Size 200A Current, 1000V Operating Voltage SLPPB35BNB
Specifications
| Country of Origin | China |
|---|---|
| Brand | Amphenol Industrial |
| Colour | Black |
| Orientation | Right Angle |
| Current | 200A |
| Height | 22.6mm |
| Model | SLPPB35BNB |
| Depth | 55.1mm |
| Connector Type | Plug |
| Width | 18mm |
| Mount Type | Panel |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | SLP |
| Termination Type | Crimp |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Pin Diameter | 8mm |
| Number of Rows | 1 |
| Wire size | 35mm² |
| Operating Voltage | 1000V |
| Standards/Approvals | RoHS Compliant, UL, TUV |
| Number of Contacts | 1 |
| Contact Gender | Female |
| Connector Gender | Female |
| Better World Claim | Renewable Energy Solution |
Key Features
- This connector is designed for 35mm² wire size for robust electrical conduction.
- Operates at a voltage of up to 1000V, suitable for high voltage EV systems.
- Features a right-angle orientation with 1 row and 1 contact for reliable connectivity.
- Contact and connector gender both are female with an 8mm pin diameter.
- Temperature range from -40°C minimum to 105°C maximum for durable operation in harsh environments.
- The connector uses crimp termination type and is constructed with copper alloy contacts and thermoplastic housing for durability.
- Panel mount type connector finished in black color for aesthetic and practical installation.
- Compliant with RoHS, UL, and TUV standards ensuring safety and quality.
Product Description
Amphenol Industrial SLPPB35BNB is a premium EV connector designed for electric vehicle power connections requiring 200A current capacity and operating voltage up to 1000V. This right-angle female SLP plug connector is engineered with a 35mm² wire size, making it suitable for demanding automotive electrical systems and renewable energy solutions.
Constructed with high-quality copper alloy contacts and a thermoplastic housing, this connector assures durability and reliable conductivity under extreme conditions, withstanding operating temperatures ranging from -40°C to 105°C.
The connector features a single row with one female contact and an 8mm pin diameter, optimized for crimp termination and panel mounting applications. Finished in black color, it combines robust mechanical strength with a compact form factor measuring 22.6mm in height, 18mm in width, and 55.1mm in depth.
Certified to meet RoHS, UL, and TUV standards, the Amphenol Industrial SLPPB35BNB supports sustainable and safe operations in electric vehicles and renewable energy systems. This connector supports 200A current and 1000V operating voltage for high-performance EV applications.
Designed for use with 35mm² cable wire, providing strong electrical contact and minimal resistance. Durable thermoplastic housing and copper alloy contacts ensure long service life. Right-angle orientation facilitates space-efficient installations in vehicle panels.
Wide temperature operating range of -40°C to 105°C supports diverse environmental conditions. Compliance to international safety and environmental standards including RoHS enhances reliability. Panel mount type ensures secure mechanical fixation and ease of integration.
Manufactured in China under strict quality controls for consistent performance.
This high-quality EV Connector is ideal for industrial, automotive, renewable energy, and manufacturing use cases requiring robust and reliable high-current power connections. Explore more connectors and electrical components suitable for your projects at EnvMart.
