WEG Overload Relay 1 NO/3 NC 29.5A F.L.C, 10A Contact Rating, 15 kW Power, 24V DC Control Voltage CWCA0



Category Overload Relay Brand WEG Condition New

Specifications

Country of Origin	Brazil
Brand	WEG
Length	58mm
Model	CWCA0
Depth	52mm
IP Rating	IP20
Width	45mm
Mount Type	DIN Rail
Series	CWCA0
Power Rating	15kW
Maximum Operating Temperature	55°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Supply Voltage	1, 50kV
Contact Voltage	690V ac
Normal State Configuration	1 NO/3 NC
Relay Contact Current	10A
Number of Auxiliary Contacts	4
Pole and Throw Configuration	4
Control Voltage	24V dc
FLC Motor Rating	29.5A

Key Features

The relay supports a power rating of 15 kW.
Control voltage is 24V DC allowing precise actuation.
It includes screw terminals and is suitable for DIN rail mounting.
The unit features 4 auxiliary contacts configured as 1 normally open and 3 normally closed.
Operating temperature range is -25°C to 55°C with IP20 protection rating.
The compact dimensions are 58mm length, 45mm width, and 52mm depth.
It complies with IEC 60034-30-1 and IEC 60947 series standards for safety and performance.
Contact voltage capacity reaches up to 690V AC.

Product Description

WEG CWCA0 overload relay 1 NO/3 NC model is a professional-grade electrical protection device rated for up to 29.5A full load current and 15 kW power applications. It operates with a control voltage of 24V DC and features screw terminal connections optimized for DIN rail mounting, ensuring a robust and secure installation in industrial electrical panels.

This overload relay has 4 auxiliary contacts arranged in a configuration of 1 normally open and 3 normally closed contacts, providing flexible control circuit integration. Its compact build with dimensions of 58mm length, 45mm width, and 52mm depth allows for efficient space-saving in control cabinets.

The device is designed for operation within a temperature range from -25°C to 55°C and includes an IP20 ingress protection rating, suitable for protected indoor environments. The relay is built in compliance with international standards including IEC 60034-30-1, IEC 60947-1, IEC 60947-2, and IEC 60947-4-1, guaranteeing safety, reliability, and compatibility with a variety of industrial electric motor control systems.

Contact ratings allow operation with voltages up to 690V AC, making this relay applicable for a broad range of motor protection scenarios in manufacturing, automation, and other electrical control installations.

The CWCA0 series from WEG represents a compact, modular, and reliable contactor overload solution, built for demanding electrical environments, and provides precise motor overload protection through proven technology.

The relay supports a power rating of 15 kW. Control voltage is 24V DC allowing precise actuation. It includes screw terminals and is suitable for DIN rail mounting. The unit features 4 auxiliary contacts configured as 1 normally open and 3 normally closed.

Operating temperature range is -25°C to 55°C with IP20 protection rating. The compact dimensions are 58mm length, 45mm width, and 52mm depth. It complies with IEC 60034-30-1 and IEC 60947 series standards for safety and performance.

Contact voltage capacity reaches up to 690V AC.

This Overload Relay is ideal for industrial automation, motor protection, manufacturing processes, and electrical control panel applications. Browse EnvMart’s Electronics & Electricals section for more WEG protective and control devices.
