ABB EF19 Electronic Overload Relay Under Contactor Mount 150A FLC, 6A Contact Rating, 690V AC 3 EF19
Specifications
| Country of Origin | China |
|---|---|
| Brand | ABB |
| Length | 89.05mm |
| Model | EF19 |
| Depth | 105.2mm |
| IP Rating | IP10, IP20 |
| Width | 117.4mm |
| Mount Type | Under Contactor Mount |
| Series | EF19 |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Flat |
| Supply Voltage | 1000V ac |
| Contact Voltage | 600V ac/dc |
| Reset Method | Automatic & Manual |
| Normal State Configuration | 1 NO/1 NC |
| Relay Contact Current | 6A |
| Number of Auxiliary Contacts | 2 |
| Pole and Throw Configuration | 3 |
| Control Voltage | 690V ac |
| FLC Motor Rating | 150A |
| Adjustable Current Range | 54 → 150 A |
Key Features
- This relay supports 1 NO/1 NC contact configuration.
- It features selectable automatic and manual reset methods.
- Adjustable current range spans from 54 to 150 A for precise overload protection.
- Built with a trip-free mechanism and phase loss sensitivity for enhanced motor safety.
- IP10 and IP20 protection ratings ensure durability in industrial environments.
- Designed to operate in temperatures from -25°C up to 70°C.
- Compact dimensions with 117.4mm width, 89.05mm length, and 105.2mm depth enable easy mounting.
- Suitable for under contactor mount applications in industrial automation control systems.
Product Description
ABB EF19 Electronic Overload Relay is engineered for fast and reliable motor protection in industrial applications. Rated at 150A full load current (FLC) with a contact current rating of 6A, this relay handles overloads and phase failures effectively to safeguard motor equipment.
The relay incorporates 1 normally open and 1 normally closed auxiliary contact with selectable reset mechanisms - both automatic and manual options allow operators to tailor its response to operational requirements.
The adjustable current range from 54 to 150 A provides flexibility for various motor sizes and load demands. Its trip class options (10E, 20E, 30E) ensure precise timing during overload conditions, while phase loss sensitivity helps prevent motor damage due to supply faults.
Constructed with robust IP10 and IP20 ratings, the EF19 series is suitable for harsh industrial environments. Its compact form factor facilitates installation under contactor mounts, minimizing panel space usage.
It complies with global IEC and UL standards (IEC/EN 60947-1, IEC/EN 60947-4-1, UL 60947-1, UL 60947-4-1), ensuring safety and performance reliability. This overload relay also features sealable operating elements and status indication for operational transparency.
This relay supports 1 NO/1 NC contact configuration. Selectable reset methods: automatic and manual. Adjustable current range from 54A to 150A for customized overload protection. Trip-free mechanism enhances motor safety.
Phase loss sensitivity prevents damage from supply interruptions. IP10 and IP20 rated for industrial environment durability. Compact dimensions optimize mounting space. Complies with IEC and UL international safety standards.
Built for under contactor mount installation. Sealable operating elements and status indication provided.
This electronic overload relay from ABB is ideal for industrial, manufacturing, and automation use cases requiring precise motor overload protection and fault indication. It is designed for integration into electrical control panels and systems where reliable motor safeguarding is critical.
Explore more products in the Overload Relay category for additional options to match your industrial electrical protection needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ABB EF19 Electronic Overload Relay has a maximum full load current (FLC) rating of 150A.
The adjustable current range for the EF19 relay spans from 54A to 150A.
This relay features a contact current rating of 6A for its auxiliary contacts.
The ABB EF19 operates within a temperature range of -25°C to 70°C.
This model is designed for under contactor mount applications.
The relay has IP10 and IP20 protection ratings, making it suitable for industrial environments.
The EF19 offers selectable reset methods, including both automatic and manual options.
This overload relay includes 2 auxiliary contacts, configured as 1 normally open (NO) and 1 normally closed (NC).
The control voltage rating for this relay is 690V AC.
This overload relay complies with IEC/EN 60947-1, IEC/EN 60947-4-1, UL 60947-1, and UL 60947-4-1 standards.
The dimensions of the EF19 are 117.4mm in width, 89.05mm in length, and 105.2mm in depth.
The relay is equipped with flat type terminals for connection.
