ABB EF96 Electronic Overload Relay 100A FLC, 6A Contact Rating, 690V AC 3-Pole EF96
Specifications
| Country of Origin | China |
|---|---|
| Brand | ABB |
| Length | 70mm |
| Model | EF96 |
| Depth | 105.2mm |
| IP Rating | IP20 |
| Width | 105.2mm |
| Mount Type | Under Contactor Mount |
| Series | EF96 |
| Maximum Operating Temperature | 70°C |
| Minimum Operating Temperature | -25°C |
| Terminal type | Flat |
| Supply Voltage | 1000V ac |
| Contact Voltage | 600V ac/dc |
| Reset Method | Automatic & Manual |
| Normal State Configuration | 1 NO/1 NC |
| Relay Contact Current | 6A |
| Number of Auxiliary Contacts | 2 |
| Pole and Throw Configuration | 3 |
| Control Voltage | 690V ac |
| FLC Motor Rating | 100A |
| Adjustable Current Range | 36 → 100 A |
Key Features
- Offers adjustable current range from 36 to 100 A for precise overload protection.
- Supports automatic and manual reset methods to suit different operational needs.
- Equipped with 2 auxiliary contacts for versatile control applications.
- Designed for under contactor mount with flat terminal type for easy installation.
- Includes trip classes 10E, 20E, and 30E selectable for flexible motor protection.
- Features trip-free mechanism with STOP and TEST function for safety and diagnostics.
- Operates reliably within temperature range of -25°C to 70°C with IP20 rating.
- Complies with IEC and UL standards ensuring international quality and safety.
Product Description
ABB EF96 Electronic Overload Relay model EF96 is engineered for fast and dependable overload protection of motors up to 100 A full load current. This electronic relay incorporates a 3-pole design with 1 normally open and 1 normally closed contact, suitable for AC control voltages of 690V, and a relay contact current rating of 6A.
The relay provides an adjustable current setting ranging from 36 to 100 A to customize protection thresholds. It offers both automatic and manual reset options, enhancing operational flexibility for industrial use. The device features a trip-free mechanism ensuring reliable interruption on overload or phase failure conditions, alongside a STOP and TEST function for maintenance and safety check purposes.
Constructed with flat terminals and designed for under-contactor mounting, it facilitates straightforward installation in control panels. The product operates within a wide temperature range from -25°C up to 70°C and has an IP20 protection rating, making it suitable for a variety of industrial environments.
Certified to IEC/EN and UL standards (60947 series), this overload relay meets stringent international safety and performance requirements. The robust design and selectable trip classes (10E, 20E, 30E) make it ideal for automated industrial motor protection in manufacturing, HVAC, and automation process control applications.
Adjustable current range from 36 to 100 Amperes for precise overload settings. Automatic and manual reset methods for operational flexibility. Trip classes selectable to match specific motor protection requirements. Incorporates 1 NO and 1 NC auxiliary contacts for control versatility.
Flat terminal design and under contactor mount facilitate easy installation. Wide operating temperature range and IP20 rating for industrial environments. Complies with IEC/EN and UL 60947 standards ensuring safety and reliability.
This EF96 electronic overload relay is essential for protecting three-phase motors against overload and phase loss conditions, ensuring high reliability and safety in industrial and commercial electrical installations. Browse more Overload Relays and contactor accessories in the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ABB EF96 overload relay has an adjustable current range from 36 to 100 A, allowing for precise overload protection settings.
This model operates reliably within a maximum temperature of 70°C, making it suitable for various industrial environments.
The contact voltage rating for the ABB EF96 is 600V AC/DC, which is suitable for various control applications.
The EF96 includes 2 auxiliary contacts, providing versatility for control applications.
This overload relay is designed for under-contactor mounting, facilitating straightforward installation in control panels.
The relay features selectable trip classes of 10E, 20E, and 30E, allowing for flexible motor protection configurations.
The EF96 has an IP20 protection rating, indicating it is suitable for use in environments where protection from solid objects is required.
The normal state configuration of the relay includes 1 normally open (NO) and 1 normally closed (NC) contact.
The supply voltage for the ABB EF96 is rated at 1000V AC, accommodating a range of industrial applications.
The EF96 supports both automatic and manual reset methods, providing operational flexibility to suit different needs.
The relay contact current rating for the ABB EF96 is 6A, which is suitable for its intended applications.
The minimum operating temperature for the ABB EF96 is -25°C, allowing it to function in colder industrial environments.
