WEG Thermal Overload Relay RW27, 1 NO/1 NC, 8A F.L.C, Adjustable Current 5.6-8 A, 1.7 W Power RW27

Free Delivery in India | Lowest Global Shipping Charges

WEG Thermal Overload Relay RW27, 1 NO/1 NC, 8A F.L.C, Adjustable Current 5.6-8 A, 1.7 W Power RW27



Category Thermal Overload Relay Brand WEG Condition New

Specifications

Country of Origin	Brazil
Brand	WEG
Length	71.7mm
Model	RW27
Depth	83.7mm
IP Rating	IP20, IP10
Width	45mm
Mount Type	Direct
Series	RW27
Power Rating	1.7W
Maximum Operating Temperature	60°C
Minimum Operating Temperature	-25°C
Terminal type	Screw
Supply Voltage	1, 50kV
Contact Voltage	690V ac
Reset Method	Automatic & Manual
Normal State Configuration	1 NO/1 NC
Relay Contact Current	5.6, 8A
Number of Auxiliary Contacts	2
Pole and Throw Configuration	3
FLC Motor Rating	8A
Adjustable Current Range	5.6 → 8 A

Key Features

This relay features a contact configuration of 1 NO and 1 NC.
The adjustable current range spans from 5.6 A to 8 A for precise control.
It supports motor FLC rating of 8 A and relay contact currents of 5.6 A and 8 A.
Equipped with screw terminals for secure wiring connections.
Automatic and manual reset methods are selectable to suit different applications.
Complies with IEC standards including IEC 60947 series for quality assurance.
Wide operating temperature range from -25°C to 60°C for varied environments.
Compact dimensions of 45mm width, 71.7mm length, and 83.7mm depth.

Product Description

WEG RW27 Thermal Overload Relay is designed for robust motor protection in industrial and commercial automation systems. Featuring a reliable 1 NO/1 NC contact configuration, this relay accommodates a motor full load current (FLC) of 8 A with ajustable current settings from 5.6 to 8 A to precisely protect against overload conditions.

The device provides both automatic and manual reset methods, allowing flexibility in system design and operation. It is constructed with screw terminals ensuring secure, stable electrical connections suitable for high-demand environments. Its build complies with rigorous IEC standards IEC 60947-4-1, IEC 60947-2, IEC 60947-1, and IEC 60034-30-1, assuring quality and safety in electrical control gear applications.

The relay operates reliably across a wide temperature range (-25°C to 60°C) and supports a contact voltage rating of 690 V AC with a power consumption of 1.7 W. Its compact form factor with dimensions 45mm (W) x 71.7mm (L) x 83.7mm (D) facilitates easy integration in control panels and motor starter units.

IP20 and IP10 protection ratings safeguard the relay against typical industrial environment dust ingress and mechanical impacts, enhancing durability and operational life. The relay's direct mount type and 3-pole configuration make it suitable for motor control and protection duties within electrical automation, manufacturing, HVAC, and other industrial applications.

This relay offers dual reset modes: hand reset and automatic, enabling adaptable usage scenarios. Phase failure sensitivity is incorporated to enhance motor protection reliability. Compact and durable design suited for rigorous industrial conditions.

Brazilian origin ensuring trusted manufacturing standards. Supports adjustable current range tailoring protection to specific motor requirements.

This product is a vital component in electrical control systems for personal and industrial safety, optimizing motor performance and protecting equipment in various industrial sectors. EnvMart provides this high quality WEG RW27 Thermal Overload Relay for effective and versatile motor overload protection solutions.
