Carlingswitch Thermal Circuit Breaker 5A Current Rating 3-Pole Wall Mount Hydraulic-Magnetic Tripping AF1X0038021F2D

The Carlingswitch AF1X0038021F2D is a high-quality thermal circuit breaker designed for industrial and commercial electrical protection applications. It supports a 5 ampere current rating across 3 poles with reliable hydraulic-magnetic tripping to manage overcurrent situations safely.

This breaker features a toggle switch reset actuator with a unique dual-color molded rocker that offers clear visual indication of the breaker status, improving maintainability and safety monitoring. Its low contact resistance ensures energy efficiency and reduced heat generation during operation.

Rated for both AC and DC voltages at 120V and 80V respectively, the breaker has a robust breaking capacity of 3000A, suitable for heavy duty circuit interruption. The medium delay break time allows selective tripping to avoid nuisance shutdowns during transient overloads.

Manufactured with a trip-free mechanism, the breaker prevents contact hold-closed conditions during faults, enhancing user and equipment safety. Full arc suppression extends contact life, reducing maintenance requirements in demanding environments.

Installation is simplified with wall mount capability and specified mounting hole dimensions. The breaker meets stringent international standards including RoHS compliance and certifications by UL, CSA, and VDE, assuring global quality and environmental safety.

This product is suitable for use in electrical panels, automation systems, HVAC controls, and various industrial machinery where precise overcurrent protection is critical. Provides reliable medium delay tripping with temperature stability to avoid false trips.

Equipped with a toggle switch reset actuator and visual state indication via a black and red two-color rocker. Features low contact resistance below 0.1 ohms for efficient current flow. Supports rated AC voltage of 120V and DC voltage of 80V with 3000A breaking capacity.

Complies with RoHS standards and includes UL, CSA, and VDE approvals for safety and quality assurance. Constructed with single pole hydraulically damped contacts and high insulation resistance over 100 megaohms. Mounting hole size of 32 x 19 mm and fixing holes of 4 mm diameter spaced at 42 mm centers.

Includes full arc suppression for extended contact life and trip-free mechanism for fault safety. Explore more Thermal Circuit Breakers and related electrical protection devices in the Electronics & Electricals category at EnvMart for your industrial and commercial needs.
