SMC 400 mm Pneumatic Piston Rod Cylinder, CP96 Series, Double Acting, Basic Mount, Air Cushion CP96
Specifications
| Country of Origin | China |
|---|---|
| Brand | SMC |
| Body Material | Urethane, Resin, Carbon Steel, Bearing Alloy, Steel, Aluminium Alloy, Die Cast Aluminium, Nitrile Rubber (NBR) |
| Length | 563mm |
| Model | CP96 |
| Mount Type | Basic |
| Series | CP96 |
| Maximum Operating Temperature | +70°C |
| Stroke Length | 400mm |
| Rod Type | Single |
| Action Type | Double Acting |
| Standards/Approvals | 4414 |
| Cushioning Type | Air Cushion |
| Piston Rod Gender | Male |
| Piston Rod Thread Standard | Metric |
| Piston Rod Thread Size | M12 x 1.25 |
Key Features
- Equipped with a 400 mm stroke length for extended reach applications.
- Features a robust basic mount and air cushioning to minimize impact and wear.
- M12 x 1.25 male metric thread piston rod ensures secure mechanical attachments.
- Constructed from urethane, resin, steel, aluminium alloys and NBR for strength and durability.
- Designed for maximum piston speed of 1000 mm/s for rapid cycle performance.
- Operating temperature rated up to +70°C for elevated ambient environments.
- ISO15552 compliant for standardized mounting and interchangeability.
- Ideal for pick-and-place, machine tending, press and clamp, conveyor diverter, and pneumatic gripper applications.
Product Description
SMC CP96 Pneumatic Piston Rod Cylinder is a double-acting actuator designed for industrial automation requiring precise linear motion control. This model features a 400 mm stroke with overall length of 563 mm, meeting ISO15552 standards for reliable and standardized operation.
The cylinder incorporates a basic mount style combined with air and bumper cushioning technology to minimize shock and wear during high-speed cycles, rated for a maximum piston velocity of 1000 mm/s. The piston rod is configured as a single male-threaded rod with an M12 x 1.25 metric thread, compatible with standard mechanical fastenings.
Manufactured from a composite of urethane, resin, carbon steel, bearing alloy, steel, aluminium alloy, die-cast aluminium, and nitrile rubber (NBR), the construction balances strength, wear resistance, and sealing performance. It is suitable for operating temperatures up to +70°C, accommodating elevated ambient conditions often encountered in industrial environments.
Applications include repetitive push-pull duties such as pick-and-place mechanisms requiring long travel, machine tending with fast reciprocating cycles, press and clamp operations necessitating controlled cushioning, conveyor diverter actuation in assembly lines, and use with pneumatic grippers needing a single-sided rod connection.
400 mm extended stroke length suitable for long reach tasks. Air cushioning and bumper cushions reduce end-of-stroke impacts and prolong component life. High piston speed capability supports rapid automation cycles. Multiple durable materials provide excellent wear resistance and sealing.
Basic mount design facilitates easy fixture integration. Conforms to ISO15552 standard for interchangeability and installation ease. High temperature rating for versatile industrial applications. Compatible with metric M12x1.25 thread mechanical attachments.
This SMC CP96 cylinder is offered as a new product from China and is an essential component for pneumatic systems in manufacturing, processing, packaging, automation, and other commercial industrial uses. Choose this CP96 model for reliable, long stroke pneumatic actuation with controlled cushioning and robust construction.
Explore more options in Pneumatic Piston Rod Cylinders with EnvMart’s extensive industrial tools and equipment catalog.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The stroke length of this model is 400 mm, allowing for extended reach applications.
It is rated for a maximum piston speed of 1000 mm/s, supporting rapid cycle performance.
The cylinder is constructed from urethane, resin, carbon steel, bearing alloy, steel, aluminium alloy, die-cast aluminium, and nitrile rubber (NBR).
This model can operate at temperatures up to +70°C, making it suitable for elevated ambient environments.
It features a basic mount type, which facilitates easy fixture integration.
The piston rod has a metric thread size of M12 x 1.25, ensuring compatibility with standard mechanical attachments.
The cylinder utilizes air cushioning to minimize impact and wear during operation.
Yes, it conforms to ISO15552 standards, ensuring reliable and standardized operation.
It is ideal for applications such as pick-and-place, machine tending, press and clamp operations, conveyor diverter actuation, and pneumatic gripper use.
The overall length of this model is 563 mm.
This cylinder is a double-acting actuator, designed for precise linear motion control.
