Europa Miniature Circuit Breaker 3-Pole 16A Type C 400V AC 10 kA Breaking Capacity EUC3P

Europa EUC3P Miniature Circuit Breaker model EUC3P is designed for industrial and commercial electrical protection applications. This 3-pole breaker with a 16A rating uses Type C tripping characteristics, making it ideal for circuits with both resistive and inductive loads such as motors and lighting systems. Rated at 400 volts AC, the breaker safely interrupts fault currents up to 10 kA, protecting wiring and connected equipment from damage.

The compact breaker measures 78 mm in width, 54 mm in height, and 87 mm in depth, allowing easy integration into standardized consumer and distribution units with 35 mm DIN rail mounting. The unit employs tunnel terminal types providing secure and reliable wire connections for copper conductors ranging from 1 mm² to 25 mm² cross-sectional area. The toggle switch actuator offers straightforward manual reset after tripping events.

Designed with IP20 protection rating, the device safeguards against accidental finger contact with live parts, ensuring operator safety in low-voltage electrical installations. Operating temperatures from -5° to 40°C make this miniature circuit breaker suitable for diverse environmental conditions often found in residential, commercial, and light industrial settings.

Designed for 3-pole electrical systems with a current rating of 16 amperes. Features Type C tripping characteristics suitable for general-purpose and inductive loads. Capable of breaking currents up to 10 kiloamperes ensuring safe disconnection.

Compact dimensions with 78mm width, 54mm height, and 87mm depth for easy DIN rail mounting. Equipped with tunnel terminal type for secure electrical connections. Rated for 400V AC voltage ensuring compatibility with a range of applications.

Toggle switch reset actuator allows convenient manual operation. IP20 rated for protection against finger access and solid foreign objects. Suitable for operating temperatures from -5° to 40°C ensuring dependable performance.

Terminal capacity accommodates wire sizes from 1mm² to 25mm².

This Miniature Circuit Breaker series conforms to international standards IEC 60898 and EN 60898, with approvals including CE and SEMKO, assuring compliance with global safety and performance requirements. It is manufactured in China and is suitable for use in residential, commercial, industrial, and automation electrical setups, providing effective protection of electrical circuits from overcurrent conditions.
