Europa Miniature Circuit Breaker 1-Pole 10A Type B 400V AC 10 kA Breaking Capacity EUC1P

Europa EUC1P Miniature Circuit Breaker (MCB) model EUC1P is a high-quality 1-pole MCB designed to provide reliable overcurrent protection in electrical circuits up to 400V AC. Its robust 10A current rating combined with Type B tripping characteristics ensures sensitive and timely interruption of fault currents to protect electrical installations and connected equipment.

The device conforms to IEC 60898 and EN 60898 standards, providing compliance assurance for various industrial, commercial, and residential electrical applications. The MCB features a 10kA breaking capacity, which is sufficient to safely interrupt high fault currents commonly encountered in electrical panels.

The compact design includes a toggle switch reset actuator for manual reset after a trip event and is engineered for DIN rail mounting (35mm) to facilitate installation in consumer units and distribution boards. The terminal capacity accommodates conductor sizes ranging from 1mm² to 25mm², allowing compatibility with a wide range of wiring configurations.

With an IP20 rating, the MCB is suitable for indoor installations where protection against finger contact is required. Its operating temperature range of -5°C to 40°C makes it suitable for diverse environmental conditions found in typical electrical enclosures.

The device's dimensions are 18mm in height, 78mm in width, and 87mm in depth, making it compact and space-efficient for electrical distribution systems. Manufactured in China, this product ensures quality and safety through CE and SEMKO approvals.

Compact 1-pole design suitable for DIN rail mounting. Rated current of 10 amperes for reliable circuit protection. Type B tripping characteristic ensures precise overload protection. Breaking capacity of 10 kiloamperes for enhanced safety.

Constructed to meet IEC 60898 and EN 60898 standards. Equipped with a toggle switch reset actuator for easy operation. IP20 rated enclosure for indoor electrical installations. Terminal capacity supports wire sizes from 1mm² to 25mm².

Suitable operating temperature range from -5°C to 40°C. Dimensions: Height 18mm, Width 78mm, Depth 87mm.

This Europa EUC1P Miniature Circuit Breaker is ideal for residential, commercial, and light industrial electrical protection applications. It provides safe disconnection and overload protection in consumer units and distribution boards, helping maintain electrical circuit integrity and user safety.
