Microchip 4-Channel 12-Bit Successive Approximation Register ADC 100 ksps, 14-Pin TSSOP MCP3204-CI/ST
Specifications
| Country of Origin | India |
|---|---|
| Resolution | 12 bit |
| Brand | Microchip |
| Height | 1.2mm |
| Length | 5.1mm |
| Model | MCP3204-CI/ST |
| Mount Type | Surface |
| Sampling rate | 100ksps |
| Series | MCP3204 |
| Input Type | Voltage |
| Maximum Operating Temperature | 85°C |
| Package Type | TSSOP |
| Minimum Operating Temperature | -40°C |
| Interface Type | SPI |
| Architecture | SAR |
| Pin Count | 14 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 2.7V |
| Number of ADCs | 4 |
Key Features
- Successive Approximation Register (SAR) architecture ensures precise conversion.
- 4 independent ADC channels enable simultaneous multi-signal measurement.
- Operates over a wide temperature range from -40°C to 85°C.
- Supports SPI interface for easy integration with microcontrollers and digital systems.
- Low supply voltage operation from 2.7V to 5.5V provides power efficiency.
- Compact 5.1 mm length and 1.2 mm height TSSOP package saves PCB space.
- Meets automotive standard AEC-Q100 for reliability in automotive applications.
- Ideal for industrial, electronic instrumentation, data acquisition, and embedded system applications.
Product Description
Microchip MCP3204-CI/ST is a 12-bit resolution analogue-to-digital converter featuring 4 channels and based on successive approximation register (SAR) architecture. It delivers a fast sampling rate of 100 ksps, suitable for applications demanding precise and rapid analogue signal digitization.
This surface-mount device comes in a compact 14-pin TSSOP package measuring 5.1 mm in length and 1.2 mm in height, enabling integration into space-constrained electronic circuits. It supports voltage input types and uses an SPI interface, making it compatible with a wide range of microcontroller and processor platforms.
The MCP3204-CI/ST operates reliably under extreme environmental conditions with a temperature range from -40°C to 85°C and supply voltage range from 2.7 V to 5.5 V. It complies with the automotive AEC-Q100 standard, ensuring durability for automotive and industrial settings.
Applications include industrial automation, electronic measurement systems, data acquisition modules, embedded systems, and other fields requiring high-accuracy analogue-to-digital conversion across multiple channels.
Successive Approximation Register architecture for high precision conversion. 4 ADC channels for multi-signal input capability. Fast 100 ksps sampling rate suitable for real-time applications. SPI communication for seamless digital interfacing.
Wide operating temperature and supply voltage ranges for robust performance. Compact 14-pin TSSOP package for efficient PCB design. Automotive qualified to AEC-Q100 standard for reliability. Widely used in industrial, laboratory, automotive, and embedded systems.
Explore more innovative semiconductor products and components at EnvMart to enhance your electronic designs and projects.
Explore more products in our Analogue to Digital Converter category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The MCP3204-CI/ST has a resolution of 12 bits, allowing for precise analogue-to-digital conversion.
This model features a maximum sampling rate of 100 ksps, suitable for applications requiring rapid signal digitization.
It supports 4 independent ADC channels, enabling simultaneous measurement of multiple signals.
The MCP3204-CI/ST operates over a temperature range from -40°C to 85°C, making it suitable for extreme environments.
It uses an SPI interface, which facilitates easy integration with microcontrollers and digital systems.
This ADC operates with a supply voltage range from 2.7V to 5.5V, ensuring power efficiency.
The MCP3204-CI/ST comes in a compact 14-pin TSSOP package, measuring 5.1 mm in length and 1.2 mm in height.
Yes, it meets the automotive standard AEC-Q100, ensuring reliability in automotive applications.
This model is suitable for industrial automation, electronic measurement systems, data acquisition modules, and embedded systems.
It is based on Successive Approximation Register (SAR) architecture, which ensures precise analogue-to-digital conversion.
The MCP3204-CI/ST supports voltage input types, which is common for various analogue signal applications.
This model is designed for surface mount, facilitating integration into space-constrained electronic circuits.
