Phoenix Contact 6-Contact 5.08 mm Pitch 320V AC/DC Pluggable Terminal Block MSTB 2.5/6-ST-5.08 BD:1-6 1758380

Phoenix Contact 1758380 Pluggable Terminal Block MSTB 2.5/6-ST-5.08 BD:1-6 is a high-quality 6-contact terminal block designed for robust and reliable electrical connections on printed circuit boards (PCBs). It supports a voltage rating of 320V AC/DC, making it suitable for industrial controls, automation equipment, and electrical assemblies.

This terminal block features a 5.08 mm pitch and a single row of contacts, which enhances compactness and efficient layout on circuit boards. The housing is made from polyamide (PA), providing excellent impact resistance and electrical insulation to ensure both operator safety and durability under demanding conditions.

The screw connection with tension sleeve allows secure wiring and ensures stable contact retention, while the terminal block’s right-angle orientation facilitates installation in tight or constrained spaces. Cable connections can accommodate wire sizes ranging from 0.2 mm² to 2.5 mm² (24 AWG to 12 AWG) to provide versatility for multiple wiring needs.

With operational temperature tolerance from -40°C to +100°C and an ingress protection rating of IP20, this terminal block is designed to withstand harsh industrial environments, including dust exposure and temperature extremes. The compact dimensions of 18.3 mm length, 25.4 mm width, and 15 mm depth contribute to its suitability for dense electronic assemblies.

Typical applications for the Phoenix Contact MSTB 2.5/6-ST-5.08 BD:1-6 series include automation systems, control cabinets, machinery wiring, and electronic device interconnects, ensuring secure and maintenance-friendly connections.

Equipped with 6 contacts for multiple cable connections. 5.08 mm pitch ensures compatibility with standard PCB layouts. Rated for 320V AC/DC voltage for versatile industrial use. Constructed with impact-resistant polyamide housing for electrical insulation and durability.

Screw connection with tension sleeve provides secure and easy wiring. Compact size with dimensions of 18.3 mm length, 25.4 mm width, and 15 mm depth. Suitable for wire sizes from 0.2 mm² to 2.5 mm² (24 AWG to 12 AWG). Right-angle orientation ideal for space-constrained installations.

Wide operating temperature range from -40°C to +100°C for harsh environments. IP20 ingress protection rating protects against dust and solid objects larger than 12 mm.

This product is manufactured in Germany according to Phoenix Contact quality standards. Explore more in the Pluggable Terminal Blocks category at EnvMart for reliable industrial electrical solutions.
