TRACOPOWER THL 25-2422 DC/DC Converter 15V 1.04A 36V DC Input 18V Input 25W PCB Shielded Metal Case 6-Pin 80°C Max Temp
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | TRACOPOWER |
| Efficiency | 89% |
| Length | 25.4mm |
| Model | THL 25-2422 |
| Depth | 10.2mm |
| Width | 25.4mm |
| Mount Type | PCB |
| Series | THL 25 |
| Maximum Operating Temperature | 80°C |
| Package Type | Shielded Metal Case with Isolated Baseplate |
| Minimum Operating Temperature | -40°C |
| MTBF | 313000h |
| Number of outputs | 2 |
| Maximum Output Power | 25W |
| Maximum Input Voltage | 36V dc |
| Minimum Input Voltage | 18V |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 797-2684Brand: TRACOPOWERManufacturers Part No.: THL 25-2422 |
| Number of Pins | 6 |
| Output Voltage 1 | 15V |
| Output Current 1 | 1.04A |
| Isolation Voltage | 1.5kV dc |
| Output Current 2 | 1040mA |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
| Output Voltage 2 | -15V |
| Wide 2 | 1 input voltage range for versatile use |
Key Features
- Offers a maximum output power of 25 watts with high efficiency up to 89%.
- Designed for industrial environments, operating between -40°C and +80°C.
- Features a 6-pin configuration and isolated baseplate for safe installation.
- Provides dual outputs of +15V and -15V for balanced power delivery.
- Equipped with isolation voltage rating of 1.5 kV DC for safety.
- Compact dimensions measuring 25.4mm length, 25.4mm width, and 10.2mm depth.
- Remote On/Off control capability for convenient power management.
- Suitable for mobile equipment, instrumentation, and industrial power architectures.
Product Description
TRACOPOWER THL 25-2422 DC/DC Converter is a compact and efficient power solution designed for industrial-grade applications requiring 15V output at 1.04A and a total power rating of 25W. This module accepts DC input voltages ranging from 18V to 36V, providing a wide 2:1 input voltage ratio suitable for diverse power environments.
Featuring a shielded metal case with an isolated baseplate, the converter is designed for PCB mounting and includes a 6-pin interface for secure connection. It achieves an efficiency rating of 89%, ensuring reliable and low-loss power conversion in demanding conditions.
The converter supports dual outputs of +15V and -15V, precisely regulated to maintain system stability and performance. Its high isolation voltage of 1.5 kV DC protects sensitive circuitry from electrical interference and noise.
Built to withstand harsh operating temperatures from -40°C to +80°C, the THL 25-2422 is suitable for rugged industrial, mobile equipment, and instrumentation applications where compact size and high reliability are essential.
Key features include ultra-compact design, remote on/off control, and a robust MTBF of 313,000 hours, ensuring long operational life. Its compact dimensions of 25.4mm by 25.4mm by 10.2mm enable integration into space-constrained systems.
High efficiency up to 89% reduces power loss and heat generation. Wide operating temperature range from -40°C to +80°C supports harsh environments. Dual output voltages offer flexibility in power system design. Isolated baseplate and shielded case improve safety and EMI performance.
Remote on/off feature enhances power management and control. Compact form factor allows use in mobile and industrial electronics. Wide input voltage range supports diverse power sources and applications. High reliability demonstrated by 313,000 hours MTBF rating.
This THL 25 Series DC-DC converter provides a reliable power source for communication systems, industrial electronics, and mobile equipment, delivering consistent performance in a small footprint.
Discover more products in the DC-DC Converter category on EnvMart to find power solutions tailored to your specific industrial and laboratory needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 25 watts.
It accepts DC input voltages ranging from 18V to 36V, providing a 2:1 input voltage ratio.
The converter provides dual outputs of +15V and -15V.
It has an efficiency rating of up to 89%.
The dimensions are 25.4mm in length, 25.4mm in width, and 10.2mm in depth.
The maximum operating temperature is 80°C.
It has an isolation voltage rating of 1.5 kV DC.
This model features two outputs.
The minimum operating temperature is -40°C.
It is designed for PCB mounting.
The MTBF is rated at 313,000 hours.
Yes, it is equipped with remote on/off control capability for convenient power management.
