TRACOPOWER Switching Regulator Through Hole SIP Package 9V DC Output 1A Output Current TSRN 1-2490A
Specifications
| Country of Origin | Taiwan |
|---|---|
| Brand | TRACOPOWER |
| Efficiency | 88% |
| Length | 11.7mm |
| Model | TSRN 1-2490A |
| Depth | 10.2mm |
| Gross Weight | 1.9kg |
| Width | 7.5mm |
| Mount Type | Through Hole |
| Series | TSRN-1 |
| Output Current | 1A |
| Maximum Operating Temperature | 85°C |
| Package Type | SIP |
| Load Regulation | ±0.4 % |
| Minimum Operating Temperature | -40°C |
| MTBF | 6000000h |
| Number of outputs | 1 |
| Ripple and Noise | 75mV Pk-Pk |
| Maximum Input Voltage | 42V dc |
| Line Regulation | ±0.2 % |
| Standards/Approvals | RoHS |
| Minimum Input Voltage | 10.5V |
| Output Voltage 1 | 9, -9V dc |
| Part Numbers | TSRN 1-xxxx have straight pins |
| Derating | 2.7 %/K above +70°C |
Key Features
- Input voltage range up to 42 V DC supports versatile power sources.
- High efficiency of up to 88% enables energy savings and reduced heat generation.
- Built-in filter capacitors and low ripple and noise at 75mV Pk-Pk ensure stable output voltage.
- Operating temperature range from -40°C to 85°C suits various industrial environments.
- Robust SIP package with dimensions 11.7 mm length, 10.2 mm depth, and 7.5 mm width fits existing TO-220 footprint.
- Low standby current of 1 mA (for 5 V output models) optimizes power consumption.
- Over-temperature and short circuit protection enhance device reliability.
- MTBF rated at 6,000,000 hours according to MIL-HDBK-217.
Product Description
TRACOPOWER TSRN 1-2490A is a high-performance switching regulator designed for through hole mounting with a compact SIP package. It provides a 9V DC output voltage and 1A output current, suitable for energy-sensitive and industrial applications.
The regulator supports a wide input voltage range up to 42 V DC, accommodating diverse power sources. Its high efficiency of up to 88% allows full load operation without the need for a heatsink or forced air cooling, reducing system complexity.
It features built-in filter capacitors and maintains a low ripple and noise level of 75mV Pk-Pk, ensuring stable and clean output voltage for sensitive electronics. Its operating temperature range from -40°C to 85°C makes it suitable for harsh industrial and commercial environments.
The SIP package dimensions are 11.7 mm in length, 10.2 mm in depth, and 7.5 mm in width, designed to fit the TO-220 footprint, facilitating straightforward PCB integration. The device also benefits from low standby current, over-temperature, and short circuit protection, making it reliable under various operating conditions.
With a Mean Time Between Failures (MTBF) of 6 million hours (MIL-HDBK-217 @ +25°C), this regulator guarantees long-term performance for demanding applications. Additionally, the product is pin compatible with LMxx linear regulators, simplifying replacements or upgrades.
This switching regulator is ideal for use in electronic components, power supplies, transformers, and voltage conversion systems found in industrial, laboratory, commercial, and manufacturing settings.
Input voltage range up to 42 V DC supports versatile power sources. High efficiency reduces heat generation and energy consumption. Low ripple noise ensures stable and clean output voltage. Wide operating temperature range for diverse environments.
Compact SIP package fits TO-220 standard PCB footprints. Over-temperature and short circuit protection for reliability. Low standby current lowers power consumption in idle states. MTBF of 6,000,000 hours for long-term reliability.
Pin compatible with LMxx linear regulators for ease of integration. Manufactured in Taiwan, Province Of China. Explore more Switching Regulators and power management components at EnvMart for your industrial and electronic application needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a 9V DC output voltage and a maximum output current of 1A.
The input voltage range for the TSRN 1-2490A is from 10.5V to 42V DC.
It has an efficiency rating of up to 88%, which helps in reducing heat generation and energy consumption.
The SIP package dimensions are 11.7 mm in length, 10.2 mm in depth, and 7.5 mm in width.
The operating temperature range for the TSRN 1-2490A is from -40°C to 85°C.
The output voltage has a ripple and noise level of 75mV Pk-Pk, ensuring stable and clean output.
This model includes over-temperature and short circuit protection to enhance device reliability.
The MTBF for the TSRN 1-2490A is rated at 6,000,000 hours according to MIL-HDBK-217.
Yes, this switching regulator is pin compatible with LMxx linear regulators, simplifying replacements or upgrades.
It uses a through hole mounting type, designed for easy integration into PCBs.
The load regulation is ±0.4%, and the line regulation is ±0.2% for this model.
This model complies with RoHS standards, ensuring it meets environmental regulations.
