TRACOPOWER 1A Surface Mount Switching Regulator 15V dc Output Voltage TSRN 1-24150SM
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | Converters / Switching Regulators TRACOPOWER Switching Regulator, Surface, 15V d |
| Brand | TRACOPOWER |
| Efficiency | 92.5% |
| Length | 15.2mm |
| Model | TSRN 1-24150SM |
| Depth | 7.2mm |
| Gross Weight | 1.7kg |
| Width | 9.3mm |
| Mount Type | Surface |
| Series | TSRN-1 |
| Output Current | 1A |
| Maximum Operating Temperature | 85°C |
| Package Type | Surface Mount |
| Load Regulation | ±0.6 % |
| Minimum Operating Temperature | -40°C |
| MTBF | 6000000h |
| Number of outputs | 1 |
| Ripple and Noise | 75mV Pk-Pk |
| Maximum Input Voltage | 42V dc |
| Line Regulation | ±0.2 % |
| Standards/Approvals | RoHS |
| Minimum Input Voltage | 7V |
| Output Voltage 1 | 15, -15V dc |
| Low standby current | Positive output circuit: 1.5 mA for stock number 755-3447, 4 mA for all other models. Negative output circuit: -3.3 / -5.5 V models: 3 mA, -9.0 / -12 V models: 7 mA and 10 mA for stock number 755-3457 |
| Derating | 1.7 %/K above +55°C (positive circuit) |
Key Features
- Compact SMD package ideal for space-constrained applications.
- Wide input voltage range up to 42 VDC enhances versatility.
- High efficiency of 92.5% for low heat dissipation and no heatsink requirement.
- Excellent line regulation of ±0.2% and load regulation of ±0.6%.
- Low ripple and noise of 75mV peak-to-peak ensures stable output.
- Operating temperature range from -40°C to 85°C for harsh environments.
- Over-temperature and short circuit protection for reliable performance.
- Remote On/Off input for flexible control in systems.
Product Description
TRACOPOWER TSRN 1-24150SM is a high-efficiency 1A surface mount step-down switching regulator providing a stable 15V DC output voltage. Designed with a compact surface mount package, it features a wide input voltage range up to 42 VDC, making it suitable for a variety of industrial and electronic applications.
This regulator achieves a high efficiency of 92.5%, allowing operation at full load without requiring a heatsink or forced air cooling. The device incorporates built-in filter capacitors and delivers excellent line regulation (±0.2%) and load regulation (±0.6%), ensuring precise voltage stability even under fluctuating input conditions.
The TSRN 1-24150SM exhibits low ripple and noise (75mV peak-to-peak), critical for noise-sensitive circuits. It is rated for operation in harsh environments with a temperature range of -40°C to 85°C and includes over-temperature and short circuit protections to maintain reliable and safe operation.
Featuring a remote On/Off input, this regulator can be easily integrated into automated systems for power management. It holds a moisture sensitivity level (MSL) rating of 1, indicating excellent robustness to moisture absorption during standard assembly processes.
With a Mean Time Between Failures (MTBF) of 6,000,000 hours and compliance with RoHS standards, the TSRN 1-24150SM is ideal for power supply needs in industrial equipment, telecommunications, automation control, and general electronics manufacturing.
Compact SMD package suitable for surface-mounted circuit boards. Wide input voltage range up to 42 VDC for flexible applications. High efficiency (92.5%) reduces power loss and heat generation. Stable output with low ripple and tight line/load regulation.
Robust operating temperature from -40°C to 85°C for reliability. Protection features against over-temperature and short circuits. Remote On/Off input supports system power management integration. Moisture sensitivity level 1 allows safe soldering without special precautions.
Explore the Electronics Components category on EnvMart to find compatible Switching Regulators and related power management devices tailored for advanced industrial and commercial electronics applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model provides a stable output voltage of 15V DC.
The maximum input voltage for the TSRN 1-24150SM is 42V DC.
It has a high efficiency rating of 92.5%, which reduces power loss and heat generation.
The operating temperature range is from -40°C to 85°C, making it suitable for harsh environments.
This unit is designed for surface mounting on circuit boards.
The dimensions are 15.2mm in length, 9.3mm in width, and 7.2mm in depth.
It includes over-temperature and short circuit protection for reliable operation.
The load regulation is ±0.6%, ensuring voltage stability under varying loads.
It offers excellent line regulation of ±0.2%.
The output ripple and noise level is 75mV peak-to-peak, which is critical for noise-sensitive applications.
The MTBF for the TSRN 1-24150SM is 6,000,000 hours, indicating a long operational lifespan.
