JST SAN Female Connector Housing 2 mm Pitch 8 Way 1 Row Straight 8P-SAN
Specifications
| Country of Origin | India |
|---|---|
| Brand | JST |
| Orientation | Straight |
| Length | 17.2mm |
| Model | 8P-SAN |
| Width | 3.25mm |
| Mount Type | Cable |
| Housing Material | Polyamide |
| Series | SAN |
| Number of Rows | 1 |
| Pitch | 2mm |
| For Use With | Crimp Connector, Board-In Connector |
| Number of Contacts | 8 |
| Connector Gender | Female |
Key Features
- The connector housing features polyamide material for durability and stability.
- It supports cable mount type and is designed for use with crimp and board-in connectors.
- The orientation of the connector is straight ensuring simple insertion and secure fit.
- Compact dimensions with length 17.2 mm and width 3.25 mm allow high-density mounting in limited PCB space.
- This housing is ideal for applications requiring a reliable 8-contact female connector interface.
- It complies with no specific standards but provides efficiency for professional electronic assemblies.
- Its SAN series design supports vertical board-in connectivity with easy insertion and locking.
Product Description
JST 8P-SAN female connector housing is a specialized 8-way single-row connector designed with a 2 mm pitch. Manufactured with durable polyamide material, it provides secure electrical connections in high-density board-in applications.
The housing is intended for cable mounting and pairs with crimp or board-in connectors offering reliable female connections. Its straight orientation facilitates seamless insertion and locking, enhancing assembly efficiency on printed circuit boards.
With compact dimensions of 17.2 mm length and 3.25 mm width, this SAN series connector housing enables economical space use without compromising mounting density. Though no formal standards or approvals are specified, the quality construction suits industrial, electronics manufacturing, and prototyping environments.
This connector housing is part of the JST SAN series, designed for vertical board-in type installations with a 2.0 mm pitch accommodating 8 contacts effectively. It is well-suited for electronic power connectors, circuit interfacing, and signal transmission use cases.
The connector housing features polyamide material for durability and stability. Supports cable mount type and use with crimp and board-in connectors. Straight orientation ensures simple insertion and secure fit. Compact size allows for high-density PCB mounting.
Designed for 8-contact female connector applications. Applicable for industrial electronics and manufacturing environments. Part of the SAN series for 2.0 mm pitch board-in connectors. Explore more Connector Housing solutions and other JST products in the Electronics & Electricals category at EnvMart for your professional engineering projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of the JST 8P-SAN connector housing is 2 mm.
This connector housing supports 8 contacts.
The orientation of this connector housing is straight, allowing for simple insertion and secure fit.
The housing is made of polyamide material, providing durability and stability.
This housing is designed for use with crimp connectors and board-in connectors.
The dimensions of this connector housing are 17.2 mm in length and 3.25 mm in width.
This connector housing is part of the JST SAN series.
Yes, its compact dimensions make it suitable for high-density mounting in limited PCB space.
The country of origin for this connector housing is India.
The mount type for this connector housing is cable mount.
The straight orientation of the housing facilitates seamless insertion and locking, enhancing assembly efficiency on printed circuit boards.
This housing is well-suited for electronic power connectors, circuit interfacing, and signal transmission in industrial electronics and manufacturing environments.
