HARWIN Archer M52 Series Straight Surface Pin Header, 20 Contacts, 1.27 mm Pitch, 1 Row, Unshrouded M52-040000P2045

HARWIN M52-040000P2045 Archer M52 Series Straight Surface Pin Header is a high-quality electronic connector designed for precise board-to-board connections in industrial, communication, and manufacturing applications. This connector features 20 gold-plated brass contacts arranged in a single row with a fine 1.27 mm pitch and a robust nylon housing, providing both electrical reliability and physical durability.

The unshrouded, straight orientation of the pin header facilitates surface mounting on printed circuit boards (PCBs), making it suitable for compact electronic assemblies where space and performance are critical. The tail pin length of 2.3 mm supports secure solder termination and stable mechanical connection.

Operating temperature ranges from -40°C to 105°C, allowing it to withstand demanding environmental conditions usually encountered in automated manufacturing, laboratory instrumentation, and communications equipment. The contact plating with gold further enhances signal integrity by preventing oxidation and ensuring consistent low-resistance connections.

This pin header supports a maximum current of 1 Amp, aligning with typical low-power electronic device requirements. It complies with the design and manufacturing standards associated with HARWIN’s Archer M52 Series, renowned for precision connectors that mate seamlessly with compatible M52 socket headers, enabling modular and scalable designs.

The product is manufactured in Taiwan, Province Of China, reflecting international quality and industrial standards. Users benefit from reliable performance across diverse sectors, including electronics assembly, industrial control systems, and high-precision instrumentation.

Features 20 male contacts arranged in a single row for compact interface. Constructed with gold-plated brass contacts ensuring excellent conductivity and corrosion resistance. Housing is made of durable nylon material suitable for harsh environments.

Designed with a 1.27 mm pitch and 2.3 mm tail pin length for precise board mounting. Operates safely within a temperature range of -40°C to 105°C. Unshrouded and straight orientation, perfect for surface mount applications.

Supports current up to 1 Amp for low power electronic circuits. Connector system is board-to-board with surface mount type for easy soldering. Manufactured in Taiwan, Province Of China, ensuring quality compliance. Compatible with matching M52 series socket headers for modular use.

Suitable for electronics manufacturing, prototyping, communication devices, industrial machinery, and laboratory instrumentation, this HARWIN pin header brings precision and robustness for demanding technical requirements. Explore more quality electronic components in this category on EnvMart to enhance your project capabilities.
