MEAN WELL Constant Current 5 Output LED Driver 24V-36V 25.2W 700mA Enclosed AC-AC IP42

MEAN WELL PCD-25-700B is a high-reliability constant current LED driver designed for indoor lighting solutions. It features a 5-output configuration delivering an output voltage range of 24V to 36V and a constant current of 700mA, with a maximum power output of 25.2W. The driver is housed in a fully isolated plastic enclosure that meets IP42 ingress protection rating, making it suitable for controlled environments.

This LED driver supports AC phase-cut dimming compatible with both leading and trailing edge dimmers, allowing flexible dimming controls in LED lighting installations. It incorporates built-in active power factor correction (PFC) to enhance energy efficiency and reduce harmonic current, complying with EN61000-3-2 Class C standards.

Designed for robust industrial use, the PCD-25-700B includes comprehensive protections such as short circuit, overload, and over temperature safeguards, ensuring long-term reliability and safety. It passes a 100% full load burn-in test under stringent quality control. The device cooling is achieved through free air convection, eliminating the need for a fan and reducing maintenance.

The product adheres to internationally recognized safety and performance standards including UL, CE, TUV, SELV, ENEC, and CSA approvals. Operating with a universal input voltage range from 180V to 295V AC, it can be used in various power environments. This LED driver is part of the PCD series offering 16W and 25W versions with specific derating guidelines based on ambient temperature.

Commonly used in indoor commercial lighting, signage, and industrial LED lamp applications, the MEAN WELL PCD-25-700B provides a reliable, efficient, and versatile power supply solution for controlled current LED arrays. It supports five independent outputs, useful for multi-channel LED configurations where individual control is required.

Equipped with AC phase-cut dimming for advanced lighting control. Built-in active PFC improves power quality and efficiency. IP42 rated fully enclosed plastic case ensures safety and insulation. Reliable protection against short circuit, overload, and overheating.

Complies with multiple international certifications for safety and EMC standards. Supports universal AC input voltage, enabling worldwide applicability. Designed for free air convection cooling for maintenance-free operation.

Undergoes exhaustive full load burn-in testing for quality assurance. Five output channels enable flexible LED system designs. Explore more industrial-grade LED Drivers and power supplies at EnvMart to enhance your lighting solutions with trusted quality and performance.
