ETA 1140-E Thermal Circuit Breaker 4A Current Rating 1-Pole Base Mount Type 250V AC 50V DC Rated Voltage 1140-E211-P1M1-4A

ETA 1140-E211-P1M1-4A Thermal Circuit Breaker is a single-pole electrical protective device designed for use in a variety of industrial and commercial electrical systems. With a current rating of 4A and a compact width of 11 mm, this base-mount breaker is ideal for saving panel space while providing reliable circuit protection.

The thermal tripping mechanism uses heating to detect overloads, providing accurate and repeatable trips with Type R tripping characteristics. It features a convenient push-to-reset button actuator, enabling quick restoration of operation after a fault is cleared.

This breaker offers a breaking capacity of 25A and supports rated voltages of 250V AC and 50V DC, making it suitable for protection of motors, transformers, solenoids, printed circuit boards, hand-held machines, appliances, and marine equipment.

Constructed with blade terminals for secure and easy wiring, and mounted using a base mount with a 4.2 mm hole size for straightforward installation. The 1140-E Series is tested and certified to meet EN 60934 (IEC 60934), UL, CSA, and VDE standards, assuring compliance and safety in demanding applications.

Typical industrial applications include motor circuits, control panels, transformers, and electrical appliances requiring precise thermal overload protection. Compact design with 11 mm width for space-efficient installation.

Base mount type with 4.2 mm mount hole size for reliable fixing. Blade terminal type for easy electrical connection. Thermal tripping mechanism with Type R tripping characteristics. Push-to-reset button actuator for quick manual reset.

Rated AC voltage 250V and DC voltage 50V. 25A breaking capacity to safely interrupt faults. Medium break time suitable for various industrial uses. Compliant with RoHS and CE directives and certified to EN 60934 and international safety standards.

For industrial, electrical automation, and manufacturing environments requiring dependable thermal circuit protection, the ETA 1140-E breaker is an optimal choice. Explore other circuit breakers and electrical components in the Electronics & Electricals category on EnvMart for comprehensive solutions.
