TE Connectivity AMPMODU HV100 Female Connector Housing 2.54 mm Pitch 10 Way 2 Row Straight HV100
Specifications
| Country of Origin | India |
|---|---|
| Brand | TE Connectivity |
| Orientation | Straight |
| Length | 25.4mm |
| Model | HV100 |
| Width | 5.06mm |
| Mount Type | PCB |
| Housing Material | Polyethylene Terephthalate |
| Series | AMPMODU HV100 |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| For Use With | PCB Connector |
| Number of Contacts | 10 |
| Connector Gender | Female |
Key Features
- The housing features kinked solder legs for secure retention on PCBs.
- Constructed from UL 94V-0 flame retardant polyethylene terephthalate thermoplastic.
- Includes board stand-offs and is suitable for vertical mounting with top entry.
- Available with mounting heights of 7 mm or 8.5 mm for stacking applications.
- Compatible with PCB connectors and designed for female connector gender.
- The 2.54 mm pitch enables reliable signal connections in electronics.
- Designed for industrial applications requiring durable and flame retardant connectors.
- Part of the AMPMODU HV100 series by TE Connectivity.
Product Description
TE Connectivity HV100 Female Connector Housing (Model HV100) is a 2.54 mm pitch, 10 way, 2 row straight connector housing designed for printed circuit board (PCB) applications. This connector housing provides secure electrical connections with kinked solder legs that ensure reliable PCB retention. The body is constructed from UL 94V-0 rated polyethylene terephthalate thermoplastic material, offering flame retardant protection for enhanced safety and durability.
The housing features board stand-offs to facilitate secure mounting and is intended for vertical PCB mounting with top entry. It is compatible with PCB connectors and supports female connector gender configurations. Two mounting height variants are available, 7 mm and 8.5 mm, enabling its use in stacking and modular electronic designs.
This series is ideal for industrial, electronic manufacturing, telecommunications, and automation applications requiring robust and safe PCB connectivity solutions that comply with demanding operational environments. The 2.54 mm pitch and 10 contacts arranged in two rows accommodate multiple signal lines in compact assemblies.
Kinked solder legs for secure PCB retention. UL 94V-0 flame retardant polyethylene terephthalate housing. Board stand-offs for stable mounting. Vertical mounting with top entry design. Available in 7 mm or 8.5 mm mounting heights for stacking.
2.54 mm pitch suitable for standard PCB connectors. Female connector gender. 10 way, 2 row configuration.
TE Connectivity’s AMPMODU HV100 connector housings are widely used in electronics industry applications and manufacturing environments. They provide reliable performance in PCB interconnections for commercial, industrial, communication, and control systems.
Choose this HV100 female connector housing for high-quality, flame-retardant PCB mounting solutions with consistent performance and flexible stacking options. Explore more Connector Housings and accessories by TE Connectivity at EnvMart for your electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pitch of the HV100 Female Connector Housing is 2.54 mm.
This connector housing features 10 contacts arranged in 2 rows.
The housing is constructed from UL 94V-0 rated polyethylene terephthalate thermoplastic, which provides flame retardant protection.
The HV100 Female Connector Housing is available in two mounting heights: 7 mm and 8.5 mm.
This model supports vertical mounting with a top entry design and includes board stand-offs for stable installation.
Yes, it is designed for compatibility with standard PCB connectors.
The orientation of this connector housing is straight.
This connector housing is suitable for industrial applications, electronic manufacturing, telecommunications, and automation.
The length of the HV100 connector housing is 25.4 mm, and the width is 5.06 mm.
This connector housing is part of the AMPMODU HV100 series by TE Connectivity.
The HV100 connector housing is designed for female connector gender configurations.
The country of origin for the HV100 Female Connector Housing is India.
