Preci-Dip 811 Series Straight Through Hole Spring Loaded Connector 11 Contacts 2.54 mm Pitch 1 Row 811-S1-011-10-016101

Preci-Dip 811-S1-011-10-016101 Spring Loaded Connector provides 11 spring-loaded contacts with a pitch of 2.54 mm arranged in one row. It features a robust and shrouded design suitable for through hole PCB mounting with a straight orientation and male contact gender. The brass contacts are plated with gold to ensure low resistance and superior corrosion resistance, supporting a continuous current of up to 3.5A and voltage up to 150V.

The housing is made from fibreglass reinforced polyethylene terephthalate, offering excellent mechanical strength and thermal stability with an operating temperature range from -55°C to 125°C. The connector complies with the UL 94V-0 standard, ensuring flame retardance and safety in demanding environments.

This connector's design includes a 4 mm plastic body height, and the spring-loaded plunger stroke length is 1.4 mm, enabling reliable electrical multipoint connections that minimize micro-discontinuities even during vibration or motion. It is ideal for industrial electronic applications, PCB assembly, test equipment, and manufacturing environments requiring high reliability and stable electrical resistance.

The product is manufactured in Switzerland, reflecting high-quality engineering standards. Its shrouded form factor protects contacts from damage and contamination during repeated mating cycles. Preci-Dip connectors from the 811 series are an excellent alternative to conventional connection solutions in industrial and laboratory settings.

Supports 3.5A current capacity suitable for various electronic circuits. Constructed with brass contact material plated with gold for reliable conductivity and corrosion resistance. Housing made from fibreglass reinforced polyethylene terephthalate ensures durability and thermal stability.

Operates reliably within a temperature range from -55°C to 125°C. Designed with straight orientation and male contact gender for versatile PCB applications. Offers solder termination for secure electrical connection. Complies with UL 94V-0 standard for flame retardance of the housing material.

Voltage rating of 150V supports typical PCB connector requirements. Shrouded design provides mechanical protection and reliable mating. Ideal for industrial, electronic, and power connection uses in manufacturing and test equipment.

Explore the wide range of professional-grade PCB connectors and spring-loaded Connectors available at EnvMart for your industrial, electronic, or laboratory needs.
