Preci-Dip 850 Series Straight Through Hole Pin Header, 9 Contacts, 1.27 mm Pitch, 1 Row, Unshrouded 850-80-009-10-001101

Preci-Dip 850-80-009-10-001101 is a high-quality straight through hole pin header featuring 9 contacts spaced at a 1.27 mm pitch in a single row configuration. It is unshrouded and designed for solder tail through-hole mounting on printed circuit boards (PCBs). The brass pins are tin plated to ensure excellent electrical conductivity and corrosion resistance, while the housing material is fiberglass reinforced polyethylene terephthalate, delivering strong insulation and mechanical stability.

Rated for a current of 1 ampere and a maximum voltage of 150 volts, this pin header supports a broad range of industrial and electronic use cases including communications equipment, control systems, and instrumentation. The contact gender is male, and the body features dimensions suitable for compact PCB designs with a body height of approximately 2.1-2.2 mm and pin tail length near 2.9-3 mm, facilitating reliable solder connections.

This pin header operates reliably between temperatures of -55°C and 125°C, making it appropriate for demanding environments. Its unshrouded straight orientation provides easy access for connections in custom wiring or prototyping scenarios. Manufactured to Swiss precision standards, it offers quality and durability for critical electronic assemblies.

The straight male pins are made of brass with tin plating for reliable conductivity. The housing is fiberglass reinforced polyethylene terephthalate, ensuring durable insulation. Rated for 1A current and 150V maximum voltage for robust performance.

Operating temperature range from -55°C to 125°C allows use in various environments. Suitable for industrial and electronic applications requiring compact, precise connections. Single row design with 1.27 mm pitch enables easy PCB layout and soldering.

Unshrouded style allows straightforward pin access for custom wiring. Manufactured in Switzerland, assuring quality and precision standards.

This Preci-Dip 850 Series PCB Pin Header is ideal for industrial, laboratory, manufacturing, and electronic equipment applications that demand reliable electrical connections and quality materials. Browse the Electronics Components category at EnvMart for additional PCB headers and electronic connectors to complete your project.
