Preci-Dip 800 Series Straight Surface Pin Header, 9 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 800-80-009-30-001101

Preci-Dip 800-80-009-30-001101 is a high-quality straight surface pin header designed for printed circuit board (PCB) applications in electronics manufacturing and assembly. This 800 Series connector offers 9 male pins arranged in a single row with a standard 2.54 mm pitch, making it suitable for various industrial and commercial PCB connector uses.

Constructed with a brass contact material plated in tin, this pin header ensures excellent conductivity and reliable electrical connection. The housing material is a glass-filled polyester, specifically fibreglass reinforced polyethylene terephthalate, providing robust mechanical strength and heat resistance.

This pin header operates efficiently across a broad temperature range of -55°C to 125°C, enabling use in diverse environments including industrial electronics, instrumentation, and control systems. It supports a maximum current of 3 amperes and voltage up to 150 volts, designed to meet the rigorous demands of high-performance electronic assemblies.

The surface mount type with solder termination facilitates straightforward PCB mounting and assembly. The unshrouded configuration allows for accessible pin contacts for easy insertion and mating with connectors or components.

The pin header features brass contact material with tin plating for corrosion resistance. It has a current rating of 3 amperes and a voltage rating of 150 volts. The housing is made from fibreglass reinforced polyethylene terephthalate for durability.

The connector supports surface mount type with solder termination and straight orientation. Operating temperature ranges from -55°C to 125°C, suitable for various environmental conditions. Unshrouded design facilitates easy mating in assembly processes.

The 9 contact pins have a pitch of 2.54 mm and a row pitch of 2.54 mm, compatible with standard PCB layouts.

Preci-Dip, known for precision and quality in connector manufacturing, delivers this 800 Series pin header as part of a comprehensive line of PCB headers for applications in telecommunications, computing, industrial controls, and other electronic products. This component is manufactured in Switzerland, reflecting adherence to high European manufacturing standards.
