SMC Pneumatic Guided Cylinder 16mm Bore Double Acting Through Hole Mount Aluminium Alloy MXS16-20

SMC MXS16-20 Pneumatic Guided Cylinder is a precision double acting pneumatic component featuring a 16mm bore and 20mm stroke length. It is designed for industrial applications requiring accurate and stable linear motion with compact form factor and robust performance.

The cylinder body is made from aluminium alloy, providing excellent strength with reduced weight and corrosion resistance. It utilizes a slide bearing guide type for smooth, guided movement, enhancing the stability and accuracy of the piston rod operation.

Operating temperatures ranging from -10°C to 60°C enable use in various manufacturing, automation, and pneumatic assembly environments. The rubber cushioning mechanism ensures quiet operation and reduces impact at stroke ends, improving machine longevity.

Installation is facilitated via the through hole mounting type, allowing flexible and straightforward mounting arrangements. The piston rod features an M5 thread for secure fixing of tooling or attachments.

Compact dimensions (87mm length, 62mm width, 40mm height) make it suitable for equipment with limited space, while the maximum piston speed of 500 mm/s supports fast and efficient actuation cycles.

Manufactured in Japan and supplied in new condition, the SMC MXS16-20 guided cylinder meets high industrial standards for pneumatic cylindric actuators used in industrial automation, laboratory automation, manufacturing plants, and pneumatic machinery.

Constructed with durable aluminium alloy body ensuring lightweight and corrosion resistance. Incorporates a slide bearing guide type for precise linear motion and stability. Operates within temperature range of -10°C to 60°C, suitable for various industrial environments.

Maximum operating pressure of 0.7 Mpa with rubber cushioning for smooth and silent operation. Through hole mount type simplifies installation and mounting flexibility. Compact dimensions: length 87mm, width 62mm, height 40mm for space-saving setups.

Piston rod thread size M5 for secure attachment of accessories or tooling. Maximum piston speed of 500 mm/s accommodates high-speed actuation requirements. Certified to be new condition and manufactured in Japan, ensuring high quality standards.
