HARWIN M22 Series Right Angle Through Hole Pin Header, 3 Contact 2 mm Pitch 1 Row Unshrouded M22-2030305
Specifications
| Country of Origin | India |
|---|---|
| Brand | HARWIN |
| Orientation | Right Angle |
| Current | 1A |
| Model | M22-2030305 |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Phosphor Bronze |
| Series | M22 |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 2mm |
| Contact Plating | Gold |
| Number of Contacts | 3 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3mm |
| Mating Pin Length | 3.5mm |
Key Features
- Constructed from durable nylon housing material suitable for high temperature soldering processes.
- Features phosphor bronze male contacts plated with gold for enhanced conductivity and corrosion resistance.
- Designed with right angle orientation for versatile board-to-board connector applications.
- Supports a continuous current rating of 1 ampere at operating temperatures from -40°C to 105°C.
- Mating pin length of 3.5 mm and tail pin length of 3 mm for secure and reliable solder termination.
- Unshrouded header provides flexibility for customized assembly and connection requirements.
- Compatible with M22 series PCB sockets, socket housings, and jumpers.
Product Description
HARWIN M22-2030305 Right Angle Through Hole Pin Header is a high-quality PCB connector designed for embedded PCs, motherboards, and advanced electronics systems. This connector is part of the M22 series featuring a 2.00 mm pitch, unshrouded single row with 3 male contacts. Its nylon housing enables it to withstand reflow soldering temperatures, making it suitable for modern manufacturing processes.
The pin header offers a right angle mounting orientation and through-hole design, compatible with a broad range of PCB socket connectors. The contact material is phosphor bronze plated with gold for superior electrical performance and corrosion resistance, rated for a maximum continuous current of 1 ampere.
It operates reliably in demanding environments with a temperature range from -40°C up to 105°C. The mating pin length of 3.5 mm ensures robust mechanical connection while the tail pin length of 3 mm facilitates secure solder joints.
This pin header is widely used in consumer electronics, communications equipment, industrial drive and control systems, and personal computing devices. The versatility of the M22 series connectors allows for multiple configuration options to suit varied PCB layout requirements.
The unshrouded design permits easy cutting to desired sizes, while the castellated housing edges provide customization flexibility. These pins mate perfectly with other M22 series components such as sockets and jumpers for comprehensive board-to-board connection solutions.
Constructed from durable nylon housing material suitable for high temperature soldering processes. Features phosphor bronze male contacts plated with gold for enhanced conductivity and corrosion resistance. Designed with right angle orientation for versatile board-to-board connector applications.
Supports a continuous current rating of 1 ampere at operating temperatures from -40°C to 105°C. Mating pin length of 3.5 mm and tail pin length of 3 mm for secure and reliable solder termination. Unshrouded header provides flexibility for customized assembly and connection requirements.
Compatible with M22 series PCB sockets, socket housings, and jumpers. Explore the full range of HARWIN PCB connectors at EnvMart for industrial, manufacturing, and electronics prototyping applications.
Explore more products in our PCB Pin Header category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a continuous current rating of 1 ampere.
The operating temperature range is from -40°C to 105°C.
The housing is made from nylon, and the contacts are phosphor bronze plated with gold.
This model features 3 male contacts.
The pitch size is 2 mm.
The mating pin length is 3.5 mm.
It uses solder termination.
It is unshrouded, allowing for flexibility in assembly and connection requirements.
The tail pin length is 3 mm.
It supports a board-to-board connector system.
The orientation is right angle, suitable for various board-to-board applications.
It is widely used in consumer electronics, communications equipment, industrial drive and control systems, and personal computing devices.
