Artesyn LPS202-M Switching Power Supply 5V DC 100W 300V DC Chassis Mount Single Output LPS200-M Series

Name: Artesyn LPS202-M Switching Power Supply 5V DC 100W 300V DC Chassis Mount Single Output LPS200-M Series
Brand: Artesyn
SKU: 125571



Category Switching Power Supplies Brand Artesyn Condition New

Specifications

Country of Origin	Philippines
Brand	Artesyn
Power	100W
Efficiency	88%
Length	127mm
Model	LPS202-M
Depth	33.6mm
Gross Weight	340g
Width	76.2mm
Mount Type	Chassis
Series	LPS200-M
Maximum Operating Temperature	50°C
Minimum Operating Temperature	0°C
Number of outputs	1
Maximum Input Voltage	300V dc
Standards/Approvals	CB, TUV, UL
Maximum Output Voltage	5V dc
SMPS Output Current	40A
Minimum Input Voltage	120, 90V dc

Key Features

The power supply supports a maximum output voltage of 5V DC.
It delivers a continuous output current of 40A with a single output.
Mount type is chassis, fitting compact industrial enclosures.
Operating temperature ranges from 0 to 50°C, ensuring reliable performance.
The LPS200-M series provides a miniature 3 x 5 inch size with high power density.
It features active power factor correction and built-in Class B EMI filter for efficiency.
Overload, overvoltage, and thermal overload protections enhance safety and durability.
The power supply is convection cooled (100W) and supports forced air cooling for higher power models.

Product Description

Artesyn LPS202-M switching power supply from the LPS200-M series delivers a reliable 5V DC output at 100W power capacity with a chassis mount configuration. This compact and miniature power supply measuring 3 x 5 inches is designed for industrial and electronic applications requiring stable and efficient DC power.

The power supply operates with a universal input voltage range from 90/120V DC to a maximum of 300V DC, with an output current capacity of 40A. It supports active power factor correction and features a built-in Class B EMI filter to reduce electromagnetic interference and enhance power efficiency, which is rated at 88%.

Designed for robust performance, it operates effectively within a temperature range of 0°C to 50°C and offers overload, overvoltage, and thermal overload protection to ensure safe and uninterrupted operation. The unit is convection cooled for 100W models, while higher power variants support forced air cooling via an isolated 12V fan output.

The LPS202-M is recognized and certified by UL, TUV, and CB standards making it suitable for use in medical, ITE, and other industrial equipment. Its chassis mount type and compact dimensions of 127mm length, 76.2mm width, and 33.6mm depth make it ideal for integration into existing power distribution systems and electronic assemblies.

The power supply delivers single-output 5V DC voltage at a maximum current of 40A. Includes active power factor correction and EMI filtering for high efficiency operation. Operating temperature is 0°C to 50°C, optimized for various industrial environments.

Safety features include thermal overload, overvoltage, and overload protections. Compact chassis mount design with dimensions of 127 x 76.2 x 33.6 mm. Power efficiency rating of 88% ensures reliable energy use. Certified to UL 60950 and 60601-1 standards with approvals from TUV and CB.

Built-in 12V isolated fan output for optional cooling support. Weight is approximately 340 grams, made in Philippines.

This power supply is ideal for diverse applications including industrial machines, medical devices, communication equipment, and power distribution systems. Explore more Artesyn LPS200-M series products and Switching Power Supplies at EnvMart for your electronic component needs.
