TRACOPOWER 3W SMD Single/Dual Output Regulated Isolated DC/DC Converter 3.3V DC, 750mA, 36V DC Input, 9V Input TES 3-2410WI

TRACOPOWER TES 3-2410WI is a 3W SMD single output regulated isolated DC/DC converter designed for applications requiring stable 3.3V DC output voltage at 750mA current. It supports a wide input voltage range of 9V to 36V DC and operates efficiently at 75%, making it suitable for power-sensitive industrial, electronic, and communication equipment.

The compact surface mount device has a low profile package (32.3mm length x 9.7mm depth), easing PCB integration in constrained spaces. The device supports 1.5kV DC isolation between input and output, improving system safety in noisy and high-voltage environments. It also includes short circuit protection and an input filter compliant with EN 55022 Class A electromagnetic interference standards.

This DC/DC converter module maintains reliable performance across a wide industrial temperature range from -40°C to +70°C, handling harsh operating conditions. The high mean time between failure (MTBF) of 1 million hours extends product life and reduces maintenance costs.

Typical uses for the TES 3-2410WI include industrial automation power supplies, communication devices, instrumentation systems, and embedded electronics requiring precise and isolated voltage regulation. The surface mount package supports lead-free reflow soldering and complies with IPC/JEDEC J-STD-020C standards.

Traco's TES 3WI series offers reliable and efficient power conversion in a compact form factor, ideal for modern electronics design where space and performance are critical. This model is manufactured in Taiwan, Province of China.

Compact surface mount DC/DC converter module delivering 3W output power. Wide 4:1 input voltage ratio supports 9V to 36V DC input range. High efficiency of approximately 75% for optimized power consumption. Supports single output voltage of 3.3V DC at a maximum current of 750mA.

Input to output isolation voltage of 1.5kV DC for enhanced safety. Operating temperature range from -40°C to 70°C for harsh environment suitability. Low profile design with dimensions 32.3mm (length) x 9.7mm (depth). Surface mount package supports modern PCB assembly and reliable soldering.

Short circuit protection and input filtering meeting EN 55022 Class A electromagnetic compatibility. High MTBF of 1,000,000 hours ensuring durability and continuous operation. Browse the Electronics & Electricals section on EnvMart for additional power supply and DC/DC Converter solutions.
