HARTING PCB Header SEK 19 Series Straight Through Hole, 40 Contacts, 2.54 mm Pitch, 2 Row, Shrouded, 1A, 1000V 09195406324

Free Delivery in India | Lowest Global Shipping Charges

HARTING PCB Header SEK 19 Series Straight Through Hole, 40 Contacts, 2.54 mm Pitch, 2 Row, Shrouded, 1A, 1000V 09195406324

Name: HARTING PCB Header SEK 19 Series Straight Through Hole, 40 Contacts, 2.54 mm Pitch, 2 Row, Shrouded, 1A, 1000V 09195406324
Brand: HARTING
SKU: 120704
Price: 5.82 USD
Availability: InStock



Category PCB Header Brand HARTING Condition New

Specifications

Country of Origin	India
Voltage	1000V
Brand	HARTING
Orientation	Straight
Current	1A
Mount Type	Through Hole
Housing Material	Polycyclohexylenedimethylene Terephthalate
Contact Material	Copper Alloy
Series	SEK 19
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	40
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board

Key Features

Constructed with copper alloy contacts plated in gold for reliable conductivity.
Housing made of Polycyclohexylenedimethylene Terephthalate ensures durability.
Designed with two rows and standard 2.54 mm pitch for versatile PCB mounting.
Offers a temperature range from -55°C up to 125°C suitable for various environments.
Features a straight orientation and through-hole mount type for easy soldering.
Includes a low profile male header with solder pins 2.9 mm in length.
Widely applicable in electronic assemblies requiring robust wire-to-board connections.
Complies with standards IDC, BT224, DIN41651, and DIN EN 60603-13 for quality assurance.

Product Description

HARTING 09195406324 PCB Header from the SEK 19 Series is a high-quality, straight through hole connector featuring 40 gold-plated copper alloy contacts organized in two rows with a 2.54 mm pitch. The shrouded design and Polycyclohexylenedimethylene Terephthalate housing material provide excellent protection and durability in demanding electrical environments.

Rated for 1A current and 1000V voltage, this male header supports a broad temperature range from -55°C to 125°C, making it suitable for industrial, electronic manufacturing, and laboratory applications. The termination type is solder, with pins of 2.9 mm length enabling secure PCB connection through a through-hole mount.

This PCB header is widely used in applications requiring reliable wire-to-board connections such as assembly lines, industrial controls, and electronic instrumentation. Its compliance with industry standards IDC, BT224, DIN41651, DIN EN 60603-13 and certifications UL: E102079, CSA: 98267 ensures robust performance and safety.

Constructed with copper alloy contacts plated with gold for enhanced conductivity and durability. Housing is made of Polycyclohexylenedimethylene Terephthalate offering mechanical strength. Accommodates 40 contacts arranged in 2 rows with a 2.54 mm pitch for compatibility with standard PCBs.

Shrouded configuration improves connector protection and mating alignment. Intended for through-hole PCB mounting with a straight orientation. Operates in a temperature range from -55°C to 125°C for diverse environmental conditions.

Meets stringent IEC and UL standards for quality and safety assurance. Select this PCB header for reliable, high-performance wire-to-board connectivity in electronic systems. Suitable for industrial, laboratory, manufacturing, and commercial electronics use cases.
