TDK Flange EMC Filter 100 A 520V AC 50Hz 60Hz Screw Termination 3 Phase B84143A0100R106

Free Delivery in India | Lowest Global Shipping Charges

TDK Flange EMC Filter 100 A 520V AC 50Hz 60Hz Screw Termination 3 Phase B84143A0100R106



Category EMI Filters & Protection Brand TDK Condition New

Specifications

Country of Origin	Hungary
Brand	TDK
Height	90mm
Length	286mm
Model	B84143A0100R106
Depth	94.5mm
Mount Type	Flange
Operating Frequency	50, 60Hz
Series	B84143A*R106
Maximum Operating Temperature	100°C
Number Of Stages	1
Resistance	480Ω
Minimum Operating Temperature	-25°C
Maximum Current	100A
Number of Phases	3
Leakage Current	3.4mA
Maximum Voltage	520V ac
Standards/Approvals	UL 1283
Termination Style	Screw
Applications include	Frequency converters for motor drives (e.g. elevators, pumps, conveyor systems and HVAC systems), Power supplies, Textile machines, Packaging machines and Machine - tools

Key Features

This EMC filter features a flange mount with screw termination for secure installation.
Optimized for long motor cables and full load operation with high insertion loss.
Compact metal case design provides robust protection and durability.
Suitable for frequency converters in motor drives such as elevators, pumps, and conveyor systems.
Ideal for power supplies, textile machines, packaging machines, and machine tools.
Operates within a temperature range of -25°C to 100°C with low leakage current of 3.4 mA.
Complies with IEC 60939 and UL 1283, CSA 22.2 No.8 standards.
Constructed and manufactured in Hungary ensuring quality and reliability.

Product Description

The TDK B84143A0100R106 flange EMC filter is a high-performance power line filter designed to suppress electromagnetic interference in industrial electrical systems. Rated for a maximum current of 100 A and maximum voltage of 520V AC, it operates efficiently at both 50Hz and 60Hz frequencies. Its compact metal casing with flange mount and screw termination ensures easy installation and long-term reliability in demanding environments.

This 3-phase, single-stage filter is optimized for long motor cables and continuous full load operation, providing excellent insertion loss characteristics to minimize noise interference. With a leakage current of 3.4 mA, it supports sensitive industrial applications while maintaining safety.

It performs reliably in harsh temperature conditions ranging from -25°C minimum to 100°C maximum, making it suitable for use in HVAC systems, frequency converters for motor drives including elevators, pumps, conveyor systems, power supplies, textile manufacturing, packaging machinery, and machine tools.

The product meets rigorous industry standards IEC 60939 and is certified with UL 1283 and CSA 22.2 No.8 approvals, ensuring compliance with international safety and performance requirements. Made in Hungary, the filter exemplifies quality engineering and robust construction with dimensions of 286 mm length, 90 mm height, and 94.5 mm depth.

Flange mounting and screw termination provide secure connection and ease of installation. Designed to handle 3-phase power systems with a maximum current of 100 A. Operates efficiently under full load with high insertion loss performance.

Compact metal case construction ensures durability and electromagnetic shielding. Low leakage current of 3.4 mA supports sensitive equipment protection. Complies with IEC 60939 standard and carries UL and CSA certifications.

Ideal for industrial sectors including motor drives, textile, packaging, HVAC, and machine tools.

This TDK flange EMC filter is an essential component for reducing electromagnetic interference and enhancing the operational stability of industrial electrical and electronic systems. For more solutions in power line filters and EMI protection devices, explore EnvMart's extensive electronics components catalog.
