ETA Thermal Circuit Breaker Single-Pole DIN Rail Mount 800mA Current Rating Toggle Switch Reset 2210-T210-K0M1-H121-0.8A



Category Circuit Breakers Brand ETA Condition New

Specifications

Country of Origin	Germany
Brand	ETA
Height	29.6mm
Model	2210-T210-K0M1-H121-0.8A
Width	12.5mm
Mount Type	DIN Rail
Current Rating	800mA
Series	2210
Terminal type	Screw
Breaking Capacity	25A
Number of Poles	1
Standards/Approvals	CE, RoHS
Rated AC Voltage	480V ac
Rated DC Voltage	65V dc
Tripping Characteristics	Type R
Tripping Mechanism	Thermal Magnetic
Reset Actuator Type	Toggle Switch
Break Time	Medium
DIN RAIL MCB+1N/C 0.8ABrand	NEUTRAL

Key Features

Thermal magnetic tripping mechanism ensures effective overload protection.
Toggle switch reset actuator allows easy manual reset.
Compatible with Top-hat and G-profile DIN rails for versatile installation.
Narrow 12.5mm width supports high-density panel mounting.
Rated AC voltage of 480V and DC voltage of 65V suitable for industrial applications.
25A breaking capacity with medium break time for reliable circuit interruption.
Build quality meets CE and RoHS standards with German origin manufacturing.
IEC Classification S/TM20 providing 30-second tripping time with approximately 5000 operation life cycles.

Product Description

ETA 2210-T210-K0M1-H121-0.8A Thermal Circuit Breaker is engineered for precision protection in industrial and commercial electrical installations. This single-pole thermal circuit breaker features a thermal magnetic tripping mechanism that provides time delay overload and short circuit protection, making it ideal for process control, telecommunications, and other professional precision applications.

The device mounts on standard DIN rails, compatible with both Top-hat and G-profile types, and fits modular housings conforming to DIN 43880. Its compact 12.5mm width facilitates high-density panel designs, optimizing space without sacrificing performance.

Rated for 480V AC and 65V DC operation, the breaker offers a breaking capacity of 25A and a medium break time, characteristic Type R tripping, and is certified to comply with CE and RoHS requirements. Originating from Germany, it assures high-quality construction and reliability.

The toggle switch actuator enables easy manual resets post-trip, and the integrated auxiliary normally closed (NC) contact supports remote signalling to indicate breaker status, enhancing monitoring in complex systems.

IEC classification S/TM20 determines the breaker’s 30-second tripping time, ensuring dependable performance with a typical operational life of 5000 cycles. All circuit breakers in the 2210 series possess blade terminals and boast insulation resistance exceeding 100 MΩ for added safety.

Thermal magnetic tripping mechanism ensures effective overload protection. Toggle switch reset actuator allows easy manual reset. Compatible with Top-hat and G-profile DIN rails for versatile installation. Narrow 12.5mm width supports high-density panel mounting.

Rated AC voltage of 480V and DC voltage of 65V suitable for industrial applications. 25A breaking capacity with medium break time for reliable circuit interruption. Build quality meets CE and RoHS standards with German origin manufacturing.

IEC Classification S/TM20 providing 30-second tripping time with approximately 5000 operation life cycles. Includes auxiliary normally closed contact for remote status signalling.

This thermal circuit breaker is suitable for use in industrial, automation, electrical distribution, and professional precision control environments. It offers dependable circuit protection while supporting compact and modular system designs.
