Telemecanique Sensors Threaded Barrel Inductive Proximity Sensor M12 x 1 PNP 24 V dc 200mA XS212SAPAL2

Telemecanique Sensors XS212SAPAL2 is a high-performance threaded barrel inductive proximity sensor engineered for precise metal object detection. It operates at a supply voltage of 24 V dc with a maximum output current of 200 mA and features a PNP output type. The sensor's body is made of durable stainless steel with an M12 x 1 thread size, measuring 54.5 mm in length and 17 mm in diameter. It is designed for non-flush mounting and provides an IP69K ingress protection rating, making it suitable for use in environments exposed to water and dust.

This sensor supports a maximum detection distance of 7 mm and can function under temperatures ranging from -25°C up to 85°C. The switching frequency of 2.5 kHz enables swift operation in automated industrial settings. Additional certifications include CSA, UL, and CE, ensuring compliance with international standards.

Ideal for applications across various sectors including railway systems, mobile equipment, material handling, packaging, food and beverage processing, and robotics. Its unshielded design allows for effective detection of metal objects without being affected by oils, dirt, or surface finish. The XS series inductive sensors provide non-contact detection, supporting both flush and non-flush mounting options along with PNP and NPN output configurations compatible with PLCs and controllers.

Equipped with threaded barrel M12 x 1 stainless steel body for robust mounting. Non-flush installation suitable for high-durability industrial use cases. IP69K rated housing ensures resistance to harsh conditions. Operating voltage range supports up to 36 V dc maximum input.

Maximum detection distance of 7 mm for reliable sensing. High switching frequency of 2.5 kHz permits rapid signal processing. Certified to CSA, UL, and CE standards for safety and performance compliance. Output type: PNP; Switching current up to 200 mA.

This inductive Proximity Sensor is a critical component for industrial automation, providing reliable metal detection capabilities in demanding environments such as manufacturing, logistics, and machinery control. Its robust design coupled with a stainless steel body and high IP rating enables use in applications requiring resistance to vibration, shock, and contamination.
