MEAN WELL SD-200 Series Single Output Enclosed Regulated Isolated DC-DC Converter, 24V Output, 36V Max Input SD-200B-24

MEAN WELL SD-200B-24 is a high-performance single output DC-DC converter designed to provide stable 24V DC output power of up to 201.6 watts. Its wide input voltage range of 19V to 36V DC allows compatibility with various power sources, making it suitable for industrial and electronic applications that require reliable DC power conversion.

The converter features a chassis mount design, enabling secure installation in control panels or equipment racks. With robust protections for short circuit, overload, and overvoltage, it ensures safe and stable operation under varying load conditions. The unit also offers an adjustable output voltage up to 30V, providing flexibility to meet specific voltage requirements.

Designed for demanding environments, it operates efficiently at 85% and maintains output voltage stability with low ripple and noise levels of 150mV Pk-Pk. The device can operate in a broad temperature range from -20°C to 60°C, suiting industrial HVAC, manufacturing, laboratory, and electrical distribution applications.

The SD-200B-24 provides a high isolation voltage of 1.5 kV AC between input and output, protecting sensitive electronics from interference and voltage spikes. It complies with recognized international standards including UL, IEC, and EN certifications, underscoring its compliance to quality and safety norms.

Its compact form factor with dimensions 215mm length, 115mm width, and 50mm depth simplifies integration into various systems without occupying excessive space, and it weighs 1.1 kg, making it manageable for installation and handling.

Supports wide input voltage range from 19V to 36V for versatile deployment. Chassis mount design facilitates secure and easy installation. High reliability with a mean time between failure (MTBF) of 218200 hours. Features short circuit, overload, and overvoltage protection for safety.

High efficiency of 85% reduces power loss and heat generation. Low ripple and noise at 150mV peak-to-peak ensure stable output. Operates reliably within temperature range of -20°C to 60°C. Provides 1.5kV isolation voltage to prevent electrical interference.

Adjustable output voltage range up to 30V for application flexibility. Complies with UL, IEC, and EN standards for quality assurance.

This DC-DC converter is ideal for industrial tools and equipment, electrical panels, power supply systems, and electronic control systems. Its versatile power input range and rugged construction make it suitable for demanding environments requiring precise DC voltage regulation and conversion. Browse EnvMart's extensive selection of power converters and components for your next electrical application.
