Microchip Operational Amplifier, 1 MHz Gain Bandwidth Product, 14-Pin SOIC, 1.8V-6V Supply MCP6004T-E/SL

Microchip MCP6004T-E/SL is a general-purpose operational amplifier designed for versatile industrial and commercial electronics applications. Featuring a 1 MHz gain bandwidth product, this 14-pin SOIC package amplifier supports low voltage operation from 1.8 to 6 volts, making it optimal for power-sensitive circuits.

Built with Microchip’s advanced CMOS process, the device consumes a minimal typical supply current of just 100 μA, enhancing efficiency in battery-powered or low-power designs. The amplifier delivers a slew rate of 0.6 V/μs, enabling it to respond rapidly to input signals while maintaining stability.

It is capable of rail-to-rail input and output operation, maximizing signal range and providing high accuracy in low-voltage applications. The device operates reliably over a wide industrial temperature range from -40°C to 125°C, suitable for harsh environments.

The MCP6004T-E/SL includes a 30 mA output current allowing it to drive a variety of analog loads effectively. With a 14-pin SOIC package and surface mounting design, it integrates seamlessly into modern circuit boards requiring multiple amplifier channels.

This Op Amp is RoHS compliant, underlining its adherence to environmental and safety standards. Typical phase margins of 90° (open loop) and 45° when driving 500 pF capacitive loads ensure robust and stable gain in diverse circuit conditions.

This operational amplifier features a supply voltage range from 1.8V to 6V suitable for various applications. It delivers a typical slew rate of 0.6 V/μs, ensuring fast response to input changes. Designed using advanced CMOS technology, it offers ultra-low supply current of approximately 100 μA.

Equipped to operate in industrial temperature ranges from -40°C up to 125°C for reliable performance. Maintains 90° phase margin typically and can handle capacitive loads with 45° phase margin at 500 pF. Features rail-to-rail input/output capability for maximum dynamic range.

Output current capability of 30 mA to drive various loads efficiently. RoHS compliant and offered in surface-mount SOIC package for easy PCB integration. Pin count of 14 pins for multi-channel operational amplifier usage in compact designs.

The MCP6004T-E/SL operational amplifier is ideally suited for industrial electronics, electronic measuring instruments, signal conditioning, control systems, and various analog signal processing applications. It supports designers in achieving efficient, low-noise amplifier chains in compact board layouts.
