Infineon Raspberry Pi Power Management HAT TLE94112ES 20V Input, 4A Output TLE94112ES
Specifications
| Country of Origin | India |
|---|---|
| Brand | Infineon |
| Model | TLE94112ES |
| Form Factor | HAT |
| Accessory Category | Power |
| Standards/Approvals | RoHS |
Key Features
- This HAT integrates reverse polarity protection for safe operations.
- Active thermal management includes embedded temperature protection.
- Customisable SPI interface expands system integration options.
- EEPROM facilitates easy driver loading and configurable settings.
- Compact design connects via Raspberry Pi's 40-pin GPIO header.
- Compatible with multiple Raspberry Pi models.
- Supports precise motor control in robotics and automation projects.
- Suitable for DIY electronics, commercial power-efficient systems, and prototyping.
Product Description
Infineon TLE94112ES Raspberry Pi Power Management HAT is a specialised accessory designed to efficiently manage multiple DC motors through the Raspberry Pi GPIO power pins. It features the TLE94112ES half-bridge driver, ensuring high reliability and seamless motor control in embedded systems.
The HAT accepts 20V input voltage and delivers a maximum output current of 4A, with each half-bridge capable of peak currents up to 0.9A. This facilitates steady operation for motors under typical loads up to 500mA when properly configured. It also supports powering the Raspberry Pi directly via an integrated DC/DC converter providing up to 2.5A output, simplifying power setups.
Key safety features include integrated reverse polarity protection and active thermal management with temperature protection to maintain robust operation. The SPI interface is customisable for flexible integration into complex systems, supported by EEPROM for easy driver loading and settings retention.
The compact form factor complies with Raspberry Pi HAT specifications, connecting via the standard 40-pin GPIO header and ensuring compatibility across Raspberry Pi models. This makes it ideal for robotics requiring precise movement control, automation requiring dynamic motor management, and educational or hobbyist projects.
Besides individual use, multiple HATs can be stacked by assigning different GPIO pins for each device's CS lines to expand motor control functionality. This flexibility also suits commercial systems prioritising power efficiency and prototyping in automotive and aeronautical applications.
Integrated reverse polarity protection for safe operation. Active thermal management with embedded temperature protection. Customisable SPI interface for expanded system integration. EEPROM provision for easy driver loading and configuration.
Compact HAT form factor compatible with Raspberry Pi GPIO headers. Motor control with peak half-bridge current up to 0.9A per channel. Supports up to 4A total output current at 20V input voltage. Integrated DC/DC converter powers Raspberry Pi with up to 2.5A output.
Ideal for robotics, automation, educational, commercial, and prototyping uses. Explore more Raspberry Pi accessories and HATs in EnvMart's Electronics & Electricals category for advanced embedded motor control solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TLE94112ES can deliver a maximum output current of 4A.
It accepts an input voltage of up to 20V.
This HAT connects via the standard 40-pin GPIO header of the Raspberry Pi.
It includes integrated reverse polarity protection and active thermal management with temperature protection.
Each half-bridge can handle peak currents up to 0.9A.
It is compatible with multiple Raspberry Pi models, adhering to HAT specifications.
The integrated DC/DC converter powers the Raspberry Pi with up to 2.5A output, simplifying power setups.
It is suitable for robotics, automation, educational projects, commercial power-efficient systems, and prototyping.
It features a customisable SPI interface for expanded system integration options.
The EEPROM facilitates easy driver loading and configurable settings retention.
The form factor of this model is HAT, which complies with Raspberry Pi specifications.
It complies with RoHS standards.
