TDK Flange EMC Filter 3 Phase 440V AC 50Hz 60Hz 50A Screw Termination B84143A0050R000

Free Delivery in India | Lowest Global Shipping Charges

TDK Flange EMC Filter 3 Phase 440V AC 50Hz 60Hz 50A Screw Termination B84143A0050R000



Category EMC Filters Brand TDK Condition New

Specifications

Country of Origin	India
Brand	TDK
Height	91mm
Length	156mm
Model	B84143A0050R000
Depth	216mm
Mount Type	Flange
Operating Frequency	50, 60Hz
Series	B84143A*R000
Maximum Operating Temperature	100°C
Resistance	2mΩ
Minimum Operating Temperature	-25°C
Maximum Current	50A
Number of Phases	3
Leakage Current	1.56mA
Maximum Voltage	440V ac
Standards/Approvals	CSA 22.2 No. 8, UL 1283
Termination Style	Screw

Key Features

Designed for screw termination to ensure secure mounting.
Optimized for effective electromagnetic compatibility (EMC) in industrial environments.
Operates efficiently from -25°C to 100°C with low leakage current of 1.56mA.
Robust flange mounting for durability and easy installation.
Low insertion loss resistance of 2 milliohms for minimal power loss.
Suitable for frequency converters used in motor drives, lifts, pumps, and conveyor systems.
Certified to meet UL 1283 and CSA 22.2 No. 8 standards ensuring safety compliance.
Compact form factor with dimensions 156mm length, 216mm depth, 91mm height.

Product Description

TDK B84143A0050R000 flange EMC filter is a high-performance 3-phase power line filter designed for industrial and commercial applications requiring robust electromagnetic interference suppression. Rated for a maximum current of 50 amperes at 440V AC with operating frequencies of 50Hz and 60Hz, this filter is ideal for motor drives, lifts, pumps, traction systems, conveyor belts, and air conditioning units. The screw termination style ensures secure and reliable electrical connections while the flange mount allows for sturdy installation in demanding environments.

This EMC filter operates effectively within a temperature range from minus 25°C up to 100°C and maintains a low leakage current of just 1.56mA, making it energy efficient and suitable for continuous operation. Its very low resistance of approximately 2 milliohms helps reduce power loss while maintaining high insertion loss to prevent interference. The filter’s compact dimensions of 156mm length, 216mm depth, and 91mm height facilitate installation in constrained equipment spaces.

Designed specifically for applications involving long motor cables under full load, the B84143-Ax-R series provides superior noise filtering performance. It is certified to comply with the UL 1283 and CSA 22.2 No. 8 safety standards, underscoring its reliability and conformity with international quality benchmarks.

Designed for screw termination ensuring safe connection. Flange mounting offers rugged installation support. Optimized for long motor cable applications and full load conditions. Low leakage current of 1.56mA enhances efficiency.

Wide operating temperature range from -25°C to 100°C. Compact size suitable for tight industrial installations. Meets UL 1283 and CSA 22.2 No. 8 safety standards. Ideal for frequency converters in various industrial equipment.

Ideal for use in industrial, manufacturing, HVAC, and power supply systems, this TDK EMC filter is a dependable solution for reducing electrical noise and improving system reliability. Explore a wide range of power line filters and EMC components on EnvMart for your electronic component needs.
