TDK Single Phase Chassis Mount EMC Power Filter 10A 250V AC 50Hz 60Hz Screw Termination B84112G0000B110

Free Delivery in India | Lowest Global Shipping Charges

TDK Single Phase Chassis Mount EMC Power Filter 10A 250V AC 50Hz 60Hz Screw Termination B84112G0000B110



Category EMC Filters Brand TDK Condition New

Specifications

Country of Origin	China
Brand	TDK
Height	29mm
Length	52mm
Model	B84112G0000B110
Depth	89.5mm
Mount Type	Chassis Mount
Operating Frequency	50, 60Hz
Series	B84112G
Maximum Operating Temperature	100°C
Number Of Stages	1
Capacitance	2pF
Minimum Operating Temperature	-25°C
Maximum Current	10A
Number of Phases	1
Leakage Current	369μA
Maximum Voltage	250V ac
Inductance	2mH
Standards/Approvals	UL 1283
Pay online using	Or choose to pay later via bank transfer
RS Stock No.	496-4762Brand: TDKManufacturers Part No.: B84112G0000B110Distrelec Article No.: 16963358
Termination Style	Screw

Key Features

Compact chassis mount design with screw termination ensures easy installation.
Operates efficiently at 50Hz and 60Hz frequencies for AC power lines.
Capacitance of 2pF and inductance of 2mH delivers effective EMI suppression.
Designed for use in industrial electronics, telecom and data systems, medical equipment, and switch-mode power supplies.
High temperature tolerance ranges from -25°C minimum to 100°C maximum operating temperature.
Leakage current is low at 369μA, compliant with UL 1283 standards.
Manufactured in China with high build quality and durability.

Product Description

TDK B84112G0000B110 is a high-performance single phase EMC filter designed for chassis mount applications in industrial electronics and power systems.

This power line filter reliably handles a maximum current of 10A and voltage of 250V AC, supporting operating frequencies of 50 and 60 Hz to accommodate different regional power standards.

Its construction features a metal case with constricted 2-line filters ensuring robust electromagnetic interference suppression suitable for sensitive electronic devices including telecom systems, switch-mode power supplies, medical equipment, and data systems.

The filter exhibits a capacitance of 2pF and inductance of 2mH, delivering superior noise suppression with minimal leakage current of 369μA, meeting UL 1283 compliance for safety and performance.

Designed to endure harsh environments, it operates within a temperature range from -25°C to 100°C. The compact dimensions (52mm length, 89.5mm depth, and 29mm height) enable easy integration into tight spaces on chassis or enclosures.

Compact chassis mount with screw termination for secure fitting. 10A max current rating for versatile industrial use. 250V AC rated voltage supports standard power lines. Effective EMI attenuation with 2pF capacitance and 2mH inductance.

Wide operating temperature range from -25°C to 100°C. Leakage current kept low at 369μA for energy efficiency. Compliance with UL 1283 for international safety standards. Robust metal construction ensures longevity and durability.

Applications include industrial electronics, medical equipment, telecom systems, switch-mode power supplies, and DC applications. This reliable EMC filter from TDK provides efficient noise suppression, enhancing system performance and electromagnetic compatibility.
