Schneider Electric TeSyS D 3-Pole Contactor, 200V AC Coil, 50A, 18.5 kW, 3 NO Auxiliary Contacts LC1D32L7
Specifications
| Country of Origin | France |
|---|---|
| Brand | Schneider Electric |
| Function | Motor Control, Resistive Load |
| Length | 85mm |
| Model | LC1D32L7 |
| Depth | 92mm |
| Width | 45mm |
| Mount Type | DIN Rail |
| Series | TeSys D |
| Power Rating | 18.5kW |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -5°C |
| Terminal type | Cable |
| Number of Poles | 3 |
| Standards/Approvals | CCC, CSA, EAC, IEC, RoHS, UL |
| Contact Voltage | 300, 690V dc |
| Coil Voltage | 200V ac |
| Normal State Configuration | 3 NO |
| Better World Claim | Designed for Disassembly |
| Contact Current | 50A |
| Number of Auxiliary Contacts | 2 |
| Auxiliary Contact Configuration | 1 NO/1 NC |
| Operational Current Ie | 32A |
| Control Circuit Voltage Uc | 200V ac |
| Contactor Application | Resistive Load, Motor Control |
| Pole and Throw Configuration | 3P |
| Screw connections | IP20 finger-safe terminals with both North American and International terminal markings |
| AC-1 | This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution |
| AC-3 | This applies to squirrel cage motors where breaking occurs while the motor is running. Example of use: all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units |
Key Features
- 3-pole contactor with 50A contact current rating and 18.5kW power rating.
- Equipped with 3 normally open auxiliary contacts for added switching functionalities.
- Suitable for motor control and resistive load applications.
- Mountable on DIN rail or panel with IP20 finger-safe screw terminals.
- Operational temperature range from -5°C to 60°C ensuring wide industrial usability.
- Designed with a bidirectional peak limiting diode to protect the coil.
- Compliant with international standards including CCC, CSA, EAC, IEC, RoHS, and UL.
- Auxiliary contact configuration includes 1 NO and 1 NC contact for flexible control options.
Product Description
Schneider Electric LC1D32L7 TeSyS D Contactor is a high-reliability 3-pole device designed for motor control and resistive load applications. This contactor operates with a 200V AC coil and supports a contact current of 50A with a power rating of 18.5 kW, suitable for industrial, manufacturing, HVAC, and automation systems.
The contactor features three normally open auxiliary contacts enhancing switching capabilities and control flexibility. Its mounting options include DIN rail and panel mounting, with IP20 rated screw connections that are finger-safe and include markings for North American and International standards.
Designed to withstand operating temperatures ranging from -5°C to 60°C, this contactor delivers robust performance in various environmental conditions. It incorporates a bidirectional peak limiting diode suppressor to protect the coil from voltage spikes, extending the service life.
Compliant with international quality and safety standards such as CCC, CSA, EAC, IEC, RoHS, and UL, the TeSyS D range ensures seamless integration into electrical control systems worldwide. The auxiliary contact configuration of 1 Normally Open and 1 Normally Closed contact supports complex control schemes.
The Contactor is suitable for use in industrial motor starters, conveyor systems, compressors, pumps, lifts, and general automation control, offering reliable switching for both resistive and motor loads.
3-pole design with 50A contact current and 18.5 kW power rating. 200V AC coil voltage for flexible control circuit integration. Mounting options include DIN Rail and panel mounting. IP20 finger-safe screw terminals with international markings.
Wide operating temperature range of -5°C to 60°C. Includes built-in auxiliary contacts and bidirectional coil protection diode. Complies with CCC, CSA, EAC, IEC, RoHS, and UL standards. Auxiliary contacts configuration: 1 NO / 1 NC.
Explore more Schneider Electric automation and control products with EnvMart for your industrial and manufacturing requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The contactor has a contact current rating of 50A.
It has a power rating of 18.5 kW.
This model operates with a coil voltage of 200V AC.
It can be mounted on DIN rail or panel.
The operational temperature range is from -5°C to 60°C.
It is equipped with 2 auxiliary contacts, configured as 1 normally open (NO) and 1 normally closed (NC).
It complies with several international standards including CCC, CSA, EAC, IEC, RoHS, and UL.
The dimensions of the contactor are 85mm in length, 45mm in width, and 92mm in depth.
It is suitable for motor control and resistive load applications.
It features IP20 finger-safe screw terminals with both North American and International markings.
The contact voltage can handle up to 300V to 690V DC.
The bidirectional peak limiting diode protects the coil from voltage spikes, enhancing its longevity.
