SMC Pneumatic Compact Cylinder Double Acting 10mm Bore 20mm Stroke Aluminium Alloy Body CXSJM10-20

SMC CXSJM10-20 is a pneumatic compact cylinder designed for industrial automation and fluid power applications. This double acting cylinder features a 10mm bore diameter and a stroke length of 20mm, providing efficient linear motion in a compact footprint. The body is constructed from aluminium alloy, combining strength with lightweight design suitable for manufacturing, packaging, material handling, and assembly machinery environments.

Equipped with a rubber bumper cushioning system, this cylinder minimizes noise and absorbs shocks during operation, enhancing equipment longevity. Its through hole mount type facilitates straightforward installation and integration into pneumatic systems. The double acting action ensures controlled movement in both directions, enabling precision in industrial automation tasks.

The cylinder operates under a maximum pressure of 0.7 MPa and supports piston speeds up to 700 mm/s, accommodating diverse industrial requirements. The double rod design with an M5 metric thread provides robust piston rod connection and compatibility with standard accessories.

The operating temperature ranges from -10 to 60 degrees Celsius, making it suitable for varied environmental conditions. With a weight of 110 grams, it ensures minimal added load on machines and structures. Originating from Japan, it reflects high craftsmanship and quality assurance required in pneumatic components.

Compact design for space-saving applications. Double acting mechanism for precise control. Aluminium alloy body ensures durability and lightweight. Rubber bumper cushioning reduces operation impact. Through hole mounting simplifies installation.

Maximum operating pressure of 0.7 MPa supports robust performance. Operating temperature range from -10°C to 60°C caters to multiple environments. Double rod type with M5 piston rod thread ensures secure connections. Lightweight construction at 110 grams for ease of use.

Manufactured in Japan, ensuring quality and reliability.

This pneumatic compact cylinder is ideal for industrial applications including manufacturing automation, laboratory equipment, HVAC systems, water treatment plants, and agricultural machinery. It offers reliable performance and durability required in demanding environments.
