SMC Pneumatic Compact Cylinder 50mm Bore, 10mm Stroke, Double Acting, Through Hole Mount, Aluminium Alloy Body CDQ2B50TF-10DZ

SMC CDQ2B50TF-10DZ Pneumatic Compact Cylinder is a high-quality pneumatic actuator designed for industrial applications requiring compactness and durability. Featuring a 50mm bore diameter and a 10mm stroke, this double acting cylinder provides reliable linear motion with through hole mounting for easy installation.

The aluminium alloy body ensures lightweight construction while maintaining strength and corrosion resistance for extended operational life. Its rubber bumper cushioning enhances the performance by reducing impact noise and wear. The cylinder operates efficiently within a pressure range of up to 1.5 MPa and withstands temperatures from -10°C to 70°C, making it suitable for diverse environments without freezing.

This product includes a magnetic piston suitable for integration with solid state switches, and the single rod type with female metric threading facilitates versatile mechanical connections. The piston can achieve speeds up to 500 mm/s, enabling quick system responses in pneumatic automation, manufacturing, and fluid power processes.

The cylinder is equipped with nitrile seals eliminating the need for regular lubrication, reducing maintenance requirements. Compact dimensions (length 48.5mm, width 71mm, height 64mm) and a gross weight of just 369g enhance its suitability for space-constrained industrial setups.

Manufactured in China and complying with industry standards, this pneumatic compact cylinder is ideal for applications in construction, manufacturing, fluid power systems, and laboratory automation where dependable actuation and efficient space utilization are critical.

Compact and lightweight design suitable for space-saving applications. Double acting cylinder with rubber bumper cushioning for smooth operation. Constructed with durable aluminium alloy for long-lasting performance. Operates at a maximum pressure of 1.5 MPa and temperature range from -10°C to 70°C.

Equipped with magnetic piston and single rod type with female metric thread. Designed for high piston speed up to 500 mm/s ensuring efficient actuation. Includes internal nitrile seals with lubrication not required. Suitable for industrial pneumatic automation, manufacturing, and fluid power systems.
