Amphenol Communications Solutions EconoStik Series Right Angle Through Hole Pin Header, 10 Contact, 2.54 10129379-910003BLF
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1500V |
| Brand | Amphenol Communications Solutions |
| Orientation | Right Angle |
| Current | 3A |
| Model | 10129379-910003BLF |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Brass |
| Series | EconoStik |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 10 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Mating Pin Length | 8.08mm |
Key Features
- Features a right-angle orientation for ease of PCB mounting.
- Includes 10 gold-plated brass male contacts for superior conductivity.
- Designed with thermoplastic housing resistant to high temperatures.
- Supports current rating of 3A and rated for 1500V voltage.
- Suitable for industrial control, test equipment, and communication devices.
- Unshrouded design with through-hole mount type for secure installation.
- Contacts are 8.08 mm in length and rated to operate between -55°C to 105°C.
- Compliant with RoHS and lead-free standards for environmental safety.
Product Description
Amphenol Communications Solutions 10129379-910003BLF EconoStik Series Right Angle Through Hole Pin Header is engineered for high-performance board-to-board connection applications. Featuring a 2.54 mm pitch and 10 male contacts, this PCB header provides robust electrical reliability and mechanical stability.
The header’s housing is made of high-temperature thermoplastic material that ensures endurance under demanding operating conditions. The brass contacts include a 1μin gold plating that enhances conductivity and provides resistance against corrosion and wear, ensuring durability through over 50 mating cycles.
Rated for a current of 3A and voltage of 1500V, this connector is suitable for use in industrial control systems, test equipment, metering devices, point-of-sale machines, set-top boxes, surveillance equipment, and vending machines. Its right-angle configuration and through-hole mounting enhance PCB layout flexibility and mechanical strength.
The contacts measure 8.08 mm in length and maintain stable performance in temperature ranges from -55°C up to 105°C. The connector system is unshrouded with custom polarization options and tail length customizations to fit specialized applications.
Right-angle orientation for efficient PCB connections. 10 gold-plated brass male contacts for superior conductivity. Thermoplastic housing designed for high-temperature resistance. 3A current rating and 1500V voltage capability.
Robust construction with tested mating cycles of 50 times minimum. Environmental compliance with RoHS and lead-free standards. Customizable mating and tail lengths for versatile engineering solutions. Ideal for industrial, commercial, and electronic consumer applications.
This Amphenol PCB header series is a dependable choice for engineers and designers seeking a high-quality connector that ensures performance and longevity in a variety of electronics applications. Explore EnvMart for more electronics components and solutions from trusted brands like Amphenol Communications Solutions.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The pin header is rated for a voltage of 1500V.
It has a current rating of 3A.
The contacts measure 8.08 mm in length.
This model features a pitch of 2.54 mm.
It utilizes a through-hole mounting type for secure installation.
The housing is made of thermoplastic, and the contacts are made of brass with gold plating.
It operates within a temperature range of -55°C to 105°C.
This header includes 10 male contacts.
Yes, it is compliant with RoHS and lead-free standards.
It features a right-angle orientation for ease of PCB mounting.
It is designed to withstand over 50 mating cycles.
It is suitable for industrial control systems, test equipment, metering devices, and communication devices.
