Amphenol Communications Solutions EconoStik Series Vertical Through Hole Pin Header, 36 Contacts, 2.54 mm 10129378-936002BLF
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 110V |
| Brand | Amphenol Communications Solutions |
| Orientation | Vertical |
| Current | 3A |
| Model | 10129378-936002BLF |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | EconoStik |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | CHINA RoHS, EU RoHS, REACH/SvHC |
| Contact Plating | Gold |
| Number of Contacts | 36 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 2.29mm |
| Mating Pin Length | 5.84mm |
Key Features
- The header features an unshrouded, vertical orientation suitable for through-hole mounting.
- Constructed with thermoplastic housing and copper alloy contacts plated with 1μin gold for enhanced conductivity.
- Operational temperature range from -55°C to 105°C ensures reliability in harsh conditions.
- Designed for board-to-board connector systems and supports customized mating and tail lengths.
- RoHS compliant with CHINA RoHS, EU RoHS, and REACH/SvHC standards.
- Durable contact plating tested for up to 50 mating cycles.
- Tail pin length is 2.29 mm and mating pin length is 5.84 mm.
- Suited for industrial control, test equipment, metering, POS machines, and surveillance equipment.
Product Description
Amphenol Communications Solutions 10129378-936002BLF EconoStik Series Vertical Through Hole Pin Header with 36 contacts provides a robust connection solution for a variety of electronic applications. Rated at 110 volts and 3 amperes, this connector supports board-to-board systems where reliable electrical performance is required under demanding conditions.
The header is fabricated from high-temperature thermoplastic housing that withstands operating temperatures ranging from -55°C to 105°C. Its contacts are made from copper alloy plated with 1μin gold, enhancing conductivity and durability. The contacts and tail feature customized lengths - 5.84 mm for mating pins and 2.29 mm for tail pins - to accommodate diverse PCB layouts.
Designed for vertical orientation and through-hole mounting, this unshrouded pin header enables secure connections in industrial control systems, test apparatus, metering devices, POS machines, set-top boxes, surveillance equipment, and vending machines. It is RoHS compliant and free of hazardous substances according to CHINA RoHS, EU RoHS, and REACH/SvHC regulatory standards.
The product supports up to 50 mating cycles, ensuring long service life in applications requiring frequent connection cycles. The 2.54 mm pitch spacing between pins maintains compatibility with standard PCB layouts, simplifying integration.
The unshrouded design facilitates easy inspection and repair of connections. Thermoplastic materials provide excellent heat resistance and mechanical strength. Gold plating on contacts reduces oxidation and ensures low contact resistance.
Board-to-board connector system enhances modular design flexibility. Ideal for industrial, laboratory, manufacturing, and commercial electronics uses.
The EconoStik series by Amphenol Communications Solutions delivers cost-effective, reliable PCB interconnect solutions. This pin header is an essential component for anyone designing or maintaining advanced electronic systems with stringent performance and compliance requirements.
For further exploration, browse additional PCB connectors and related Amphenol Communications Solutions products on EnvMart to find compatible accessories and complementary components.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for 110 volts.
The maximum operating temperature is 105°C.
It features 36 contacts.
The pitch size is 2.54 mm.
The housing is made from thermoplastic, and the contacts are copper alloy plated with gold.
The tail pin length is 2.29 mm.
It supports through-hole mounting.
Yes, it is RoHS compliant with CHINA RoHS, EU RoHS, and REACH/SvHC standards.
The current rating is 3 amperes.
The mating pin length is 5.84 mm.
It is suited for industrial control, test equipment, metering, POS machines, and surveillance equipment.
It utilizes a board-to-board connector system.
