Amphenol Communications Solutions EconoStik Series Vertical Through Hole Pin Header, 2 Contacts, 2.54 mm 10129378-902001BLF
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 110V |
| Brand | Amphenol Communications Solutions |
| Orientation | Vertical |
| Current | 3A |
| Model | 10129378-902001BLF |
| Mount Type | Through Hole |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | EconoStik |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Standards/Approvals | CHINA RoHS, EU RoHS, REACH/SvHC |
| Contact Plating | Gold |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 3.05mm |
| Mating Pin Length | 5.84mm |
Key Features
- The pin header has a 2.54 mm pitch for standard spacing on PCB boards.
- It supports a continuous current of up to 3A for efficient power transmission.
- Constructed with thermoplastic housing that provides high temperature resistance.
- Features a vertical orientation with unshrouded male contacts suitable for through-hole mounting.
- The contact pins are made of copper alloy with 1 μin gold plating, ensuring excellent conductivity and durability.
- Tail pin length is 3.05 mm, and mating pin length is 5.84 mm for secure connections.
- Rated for operation between -55°C and 105°C for wide environmental tolerance.
- Complies with CHINA RoHS, EU RoHS, and REACH/SvHC environmental standards, delivering lead-free construction.
Product Description
Amphenol Communications Solutions 10129378-902001BLF is a Vertical Through Hole Pin Header from the EconoStik Series designed for precision and reliability in electronic applications. With 2 contacts arranged in a single row and a 2.54 mm pitch, this pin header is optimized for standard PCB board spacing.
The pin header uses thermoplastic housing material known for its high temperature tolerance. Contacts are made of copper alloy plated with 1 μin of gold, tested for up to 50 mating cycles to ensure longevity and consistent performance. Tail pin length of 3.05 mm and mating pin length of 5.84 mm provide secure solder connections in through-hole mounting.
Operational temperature range spans from -55°C to 105°C, allowing usage in diverse industrial environments. The product supports a current rating of 3A and a voltage of 110V, suitable for many board-to-board electrical connections.
This unshrouded male connector fits a vertical orientation for straightforward assembly and is compliant with several environmental standards including CHINA RoHS, EU RoHS, and REACH/SvHC, ensuring lead-free and eco-friendly manufacturing processes.
Applications for this pin header include industrial control systems, metering, test equipment, point-of-sale terminals, set-top boxes, surveillance equipment, and vending machines. It is ideal wherever robust and reliable board-to-board interconnections are required.
The pin header features a 2.54 mm pitch with 2 contacts. Constructed with thermoplastic housing and gold-plated copper alloy contacts. Designed for through-hole solder mount and vertical orientation. Supports 3A current and 110V voltage ratings.
Operating temperature range from -55°C to 105°C. Compliant with CHINA RoHS, EU RoHS, and REACH/SvHC standards. Suitable for industrial, commercial electronics, and communication equipment. Tail and mating pin lengths are customized for secure connections.
Explore more PCB Headers and connectors at EnvMart for your electronic component requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a continuous current of up to 3A, making it suitable for efficient power transmission in electronic applications.
This model is rated for operation at 110V, which is appropriate for various board-to-board electrical connections.
The pin header features a 2.54 mm pitch, which is standard for PCB board spacing.
The contacts are made of copper alloy and are plated with 1 μin of gold to ensure excellent conductivity and durability.
It operates effectively within a temperature range of -55°C to 105°C, allowing for use in diverse environments.
The tail pin length is 3.05 mm, while the mating pin length is 5.84 mm, providing secure connections during installation.
This model is designed for through-hole mounting, which allows for secure solder connections on PCB boards.
Yes, it complies with CHINA RoHS, EU RoHS, and REACH/SvHC standards, ensuring lead-free construction.
It features a vertical orientation, which facilitates straightforward assembly in electronic applications.
This pin header has 2 contacts arranged in a single row, optimized for standard PCB applications.
The termination type is solder, which is typical for secure connections in electronic assemblies.
It is suitable for various applications including industrial control systems, metering, test equipment, and point-of-sale terminals.
