Vishay Single Layer Ceramic Capacitor 680 pF 10 kV dc ±20% Through Hole Radial Lead Disc HVCC203Y6P681MEAX

Free Delivery in India | Lowest Global Shipping Charges

Vishay Single Layer Ceramic Capacitor 680 pF 10 kV dc ±20% Through Hole Radial Lead Disc HVCC203Y6P681MEAX

Name: Vishay Single Layer Ceramic Capacitor 680 pF 10 kV dc ±20% Through Hole Radial Lead Disc HVCC203Y6P681MEAX
Brand: Vishay
SKU: 107190
Price: 2.54 USD
Availability: InStock



Category Single Layer Ceramic Capacitors Brand Vishay Condition New

Specifications

Country of Origin	China
Voltage	10kV dc
Diameter	15mm
Brand	Vishay
Height	19mm
Length	45mm
Model	HVCC203Y6P681MEAX
Packaging	Bulk
Mount Type	Through Hole
Series	HVCC
Maximum Operating Temperature	105°C
Tolerance	±20 %
Capacitance	680pF
Minimum Operating Temperature	-30°C
Terminal type	Radial
Dissipation Factor	1.5%
Standards/Approvals	RoHS
Package/Case	Disc
Suppression Class	Class II

Key Features

Features a through-hole radial lead mounting for easy PCB assembly.
Disc type ceramic capacitor with a high operating temperature of up to 105 °C.
Capacitor body diameter of 15 mm, length of 45 mm, and height of 19 mm.
Supplied in bulk packaging with radial tinned copper clad steel wire leads.
Low dissipation factor of 1.5% ensuring minimal energy loss in circuits.
Compliant with RoHS standards and classified as Class II suppression capacitor.
Designed for operation between - 30 °C and 105 °C, suitable for varied environmental conditions.
Silver-plated ceramic disc with radial terminals providing reliable electrical connections.

Product Description

Vishay HVCC203Y6P681MEAX is a single layer ceramic capacitor designed for high voltage dc applications with a capacitance of 680 pF and voltage rating of 10 kV dc. This through-hole capacitor features radial leads soldered onto printed circuit boards for durable assemblies. The disc type body measures 15 mm in diameter, 45 mm in length, and 19 mm in height, engineered to operate reliably at temperatures up to 105 °C.

Manufactured with a ceramic disc that is silver-plated on both sides, the capacitor's connection leads consist of tinned copper clad steel wire with diameters of 0.65 mm and 0.80 mm, optimizing electrical and mechanical performance. It exhibits a low dissipation factor of 1.5%, minimizing energy loss and ensuring stable operation in power and signal circuits.

Rated with a tolerance of ±20%, the capacitor operates effectively in harsh environments between - 30 °C and 105 °C. Its construction complies with RoHS environmental standards and is categorized under Class II suppression capacitors suitable for noise reduction and filtering in electronics, power supplies, industrial, laboratory, HVAC, and manufacturing equipment.

Through-hole radial lead design facilitates easy PCB through-hole mounting and soldering. Silver-plated ceramic disc construction enhances durability and electrical reliability. High voltage rating of 10 kV dc supports industrial and high power electronics.

Compliance with RoHS ensures environmental safety and regulatory adherence. Low dissipation factor improves energy efficiency of circuits. Wide temperature range tolerance from - 30 °C to 105 °C broadens application scope.

Suitable for industrial, electronic component manufacturing, power supply modules, and HVAC system integration.

Choose Vishay capacitors for proven reliability and performance in demanding electrical and industrial environments. Explore more in the Single Layer Ceramic Capacitors category on EnvMart.
