TDK-Lambda CC-E DC/DC Converter 5V DC Output 300mA 18V Input Surface Mount 1.5W Power CC1R5-1205SR-E

TDK-Lambda CC1R5-1205SR-E is a high-quality DC/DC Converter optimized for delivering a 5V DC output at 300mA current with a maximum output power of 1.5W. This compact device is designed for surface mount applications and is ideal for efficient voltage conversion in electronic circuits.

The converter accepts input voltages ranging from 9V to 18V, supporting versatile applications with an input ratio of 2:1. Featuring a 7-pin surface mount package with dimensions measuring 19.81mm in length, 16.5mm in width, and 16.6mm in depth, it offers a minimal footprint suitable for space-constrained designs.

Safety is enhanced by an isolation voltage of 500V between input and output, making it suitable for equipment requiring electrical separation. The device operates reliably across a broad temperature range from -40°C to 85°C, ensuring stable performance in demanding industrial, telecommunications, and consumer electronics environments.

With an efficiency of approximately 78%, it minimizes power loss, contributing to energy-efficient system designs. Weighing only 3.2 grams, the converter is lightweight and easy to incorporate into various electronic assemblies.

This single output DC/DC converter provides a stable output voltage with an adjustment range of ±3%, supporting precision power delivery. It is part of the renowned CC-E series by TDK-Lambda, known for ultra-compact size and reliable performance.

Operates with an input voltage range of 9V to 18V to match diverse power requirements. Output voltage fixed at 5V DC with 300mA output current for low-power applications. Surface mount package for modern PCB assembly methods.

Isolation voltage of 500V enhances electrical safety. Wide operating temperature range for industrial and commercial use. Low weight of 3.2g supports lightweight, compact systems. High efficiency of 78% reduces energy consumption.

Dimensions 19.81mm x 16.5mm x 16.6mm fit tight design constraints.

Common applications include telecommunication equipment voltage conversion, industrial electronics power supply, and consumer electronic devices requiring reliable DC voltage conversion. This product is manufactured in Japan to high quality standards and ensures dependable performance in a variety of technical environments.
