TDK-Lambda CC-E Surface Mount DC/DC Converter 3.3V DC 1.2A 6W 9-18V Input CC6-1203SR-E
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | TDK-Lambda |
| Efficiency | 0.78% |
| Length | 22.86mm |
| Model | CC6-1203SR-E |
| Depth | 21.1mm |
| Gross Weight | 5.8g |
| Width | 22.8mm |
| Mount Type | Surface |
| Series | CC-E |
| Maximum Operating Temperature | 85°C |
| Package Type | Surface Mount |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 1 |
| Maximum Output Power | 6W |
| Maximum Input Voltage | 18V |
| Minimum Input Voltage | 9V dc |
| Number of Pins | 7 |
| Output Voltage 1 | 3.3V dc |
| Output Current 1 | 1.2A |
| Isolation Voltage | 500V |
| Input Ratio | 2:1 |
| Input Ratio2 | 1 |
Key Features
- Compact surface mount package suitable for PCB integration.
- Input voltage range from 9V DC minimum to 18V maximum ensures versatile use.
- Single output delivers stable 3.3V DC at 1.2A current.
- High isolation voltage of 500V between input and output enhances safety.
- Operates reliably within -40°C to 85°C temperature range.
- Outstanding efficiency of 78% minimizes power loss.
- Small footprint dimensions of approximately 22.86mm length, 22.8mm width, and 21.1mm depth.
- Lightweight unit weighing only 5.8 grams.
Product Description
TDK-Lambda CC6-1203SR-E is a high-performance DC/DC converter designed for efficient voltage step-down with electrical isolation. This surface mount converter provides a regulated 3.3V DC output from an input range of 9V to 18V DC, supporting up to 1.2A load current with a maximum output power of 6W.
The CC-E series converters feature a compact footprint measuring 22.86mm in length, 22.8mm in width, and 21.1mm in depth, with a weight of just 5.8 grams. They are surface mount devices with 7 pins, optimized for integration on printed circuit boards within telecommunications, industrial, and consumer electronic equipment.
With an isolation voltage rating of 500V, this converter enhances system safety by providing electrical isolation between input and output circuits. The device operates reliably in ambient temperatures ranging from -40°C to +85°C, making it suitable for challenging environments.
The CC6-1203SR-E provides a stable 3.3V DC output with 1.2A current, making it ideal for powering low-voltage digital logic and control circuits. Its efficiency is approximately 78%, reducing heat dissipation and improving overall system reliability.
Applications include use in telecommunication systems, industrial automation devices, and consumer electronics where precise and reliable DC power conversion is needed. The device’s wide input voltage window and isolation capabilities also make it suitable for systems requiring galvanic isolation.
Compact surface mount package suitable for PCB integration. Input voltage range from 9V DC minimum to 18V maximum ensures versatile use. Single output delivers stable 3.3V DC at 1.2A current. High isolation voltage of 500V between input and output enhances safety.
Operates reliably within -40°C to 85°C temperature range. Outstanding efficiency of 78% minimizes power loss. Small footprint dimensions of approximately 22.86mm length, 22.8mm width, and 21.1mm depth. Lightweight unit weighing only 5.8 grams.
Ideal for telecommunications, industrial, and consumer electronic applications requiring DC voltage conversion. For more DC/DC Converter options and detailed product selection, explore the Electronics & Electricals category at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input voltage range for this model is from 9V DC minimum to 18V maximum.
It delivers a stable output of 3.3V DC at a current of 1.2A.
The maximum output power of this unit is 6W.
This model has dimensions of approximately 22.86mm in length, 22.8mm in width, and 21.1mm in depth.
The weight of this unit is 5.8 grams.
This model has an efficiency rating of approximately 78%.
The isolation voltage between the input and output is rated at 500V.
It operates reliably within a temperature range of -40°C to +85°C.
This DC/DC converter features a single output.
This unit is designed for surface mounting.
It has a total of 7 pins.
This model is suitable for telecommunications, industrial automation devices, and consumer electronics requiring DC voltage conversion.
