STMicroelectronics High Side Power Switch IC, Surface Mount SOIC 8-Pin, 8V-35V Supply, 0.5A Operating Current L6375S
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.25mm |
| Length | 5mm |
| Model | L6375S |
| Width | 4mm |
| Mount Type | Surface |
| Series | L6375S |
| Maximum Operating Temperature | 85°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -25°C |
| Operating Current | 0.5A |
| Number of outputs | 1 |
| Standards/Approvals | IEC 61000-4-4 |
| Pin Count | 8 |
| Maximum Supply Voltage | 35V |
| Minimum Supply Voltage | 8V |
Key Features
- The device incorporates thermal shutdown for protection against overheating.
- It features controlled output voltage slew rate to minimize electromagnetic interference.
- Internal current limiting enhances device safety and reliability.
- Open ground and short circuit protections ensure robust operation in inductive or resistive load applications.
- Compact SOIC 8-pin package provides ease of surface mounting in tight PCB layouts.
- Operating temperature ranges from -25°C to 85°C for varied industrial environments.
- Complies with IEC 61000-4-4 electromagnetic compatibility standard.
- A single output high side driver, series L6375S, designed for efficient power management.
Product Description
STMicroelectronics L6375S is a monolithic intelligent high side power switch designed for driving inductive or resistive loads. It supports a wide supply voltage range from 8V to 35V and an operating current of 0.5A, making it suitable for industrial and electronic applications requiring reliable power switching capabilities.
The integrated device features controlled output voltage slew rate which reduces electrical noise and electromagnetic interference, essential for sensitive electronic circuits. Protection mechanisms such as internal current limiting and thermal shutdown safeguard the switch from electrical overload and overheating conditions respectively.
Open ground protection enhances safety by preventing damage during improper grounding conditions. Packaged in a compact 8-pin SOIC surface mount format with dimensions approximately 5mm in length, 4mm width, and 1.25mm height, the L6375S facilitates efficient PCB designs with limited space availability.
Its operating temperature range from -25°C to 85°C allows deployment in diverse environments including automotive electronics, industrial automation, and power management systems. The device is compliant with the IEC 61000-4-4 standard, ensuring electromagnetic compatibility under electrical fast transient conditions.
This high side intelligent power switch is ideal for applications requiring efficient load driving with safety and thermal protections integrated. It supports powering loads with a single output channel and is suitable for surface mounting on electronic circuit boards.
The device ensures reliable switching for resistive and inductive loads. Incorporates advanced protections improving product lifetime and safety. Compact SOIC package suitable for dense PCB layouts. Wide operating voltage and temperature range increases application flexibility.
Compliance with international EMC standards enhances system robustness. Ideal for industrial, automotive, and power management applications. Efficient load control with controlled voltage slew rate reduces EMI. Thermal and current protections prevent costly device failures.
Explore more power management semiconductors and related electronic components in the Electronics & Electricals category on EnvMart for your industrial and technical requirements.
Explore more products in our Power Switch IC category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The L6375S operates within a supply voltage range of 8V to 35V.
The maximum operating temperature for the L6375S is 85°C.
This model features a single output channel.
The operating current for the L6375S is 0.5A.
The dimensions of the L6375S are approximately 5mm in length, 4mm in width, and 1.25mm in height.
The L6375S is packaged in a compact SOIC 8-pin surface mount format.
The device includes thermal shutdown, internal current limiting, and open ground protection to enhance safety and reliability.
Yes, it complies with the IEC 61000-4-4 electromagnetic compatibility standard.
The minimum operating temperature for the L6375S is -25°C.
This power switch is suitable for applications in industrial automation, automotive electronics, and power management systems.
It features a controlled output voltage slew rate, which helps to reduce electrical noise and electromagnetic interference.
The L6375S is manufactured in India.
